Уводзіны
This manual provides essential information for the proper installation, operation, and maintenance of your Russound DMS-3.1 Network Player Digital Media Streamer. The DMS-3.1 is designed to integrate internet audio into your Russound MCA system, offering enhanced performance and access to various streaming services. Please read this manual thoroughly before using the device to ensure optimal performance and longevity.
Малюнак 1: Спераду view of the Russound DMS-3.1 Network Player Digital Media Streamer. This image displays the compact design of the unit, typically featuring indicator lights and possibly a power button on the front panel.
Настройка
1. Распакаванне
- Carefully remove the DMS-3.1 unit and all accessories from the packaging.
- Verify that all components are present: DMS-3.1 unit, power adapter, and this instruction manual.
- Захавайце ўпакоўку для будучай транспарціроўкі або захоўвання.
2. Падключэнне да сілкавання
- Connect the provided power adapter to the DC input port on the rear of the DMS-3.1.
- Падключыце адаптар сілкавання да стандартнай электрычнай разеткі.
- The unit will power on automatically or may require a press of the power button if present.
3. Падключэнне да сеткі
- For optimal performance, connect the DMS-3.1 to your local network using an Ethernet cable (RJ45) from the unit's LAN port to your router or network switch.
- While some functionality may support Wi-Fi, a wired connection is recommended for stable streaming.
4. Audio/Video Connections
- HDMI: Connect an HDMI cable from the DMS-3.1 HDMI output to an available HDMI input on your television or AV receiver.
- USB: The USB port can be used for connecting external storage devices for local media playback or for firmware updates.
- Аналаг: Connect the analog audio outputs (if available) to your Russound MCA system or other audio amplifier using appropriate RCA cables.
5. Initial Configuration and Firmware Update
- After connecting, power on all connected devices.
- Access the DMS-3.1's web interface or dedicated control app (e.g., Russound App) from a compatible device (laptop, tablet, smartphone) connected to the same network.
- Follow the on-screen instructions for initial network setup and configuration.
- It is highly recommended to check for and install the latest firmware updates to ensure access to all features and performance improvements. Firmware updates can often be initiated through the web interface or app, or by downloading from the Russound support website and installing via USB.
Інструкцыя па эксплуатацыі
1. Controlling the DMS-3.1
- The primary method of control is through the dedicated Russound control app, available for compatible tablets and smartphones.
- The unit can also be integrated and controlled via Russound MDK C5 keypads or other compatible Russound control systems.
- Ensure your control device is connected to the same network as the DMS-3.1.
2. Streaming Media
- Інтэрнэт-радыё: Access a wide variety of internet radio stations through the control app.
- Музычныя паслугі: Integrate and stream from popular music services such as Pandora and Sirius XM (subscription may be required).
- AirPlay: Utilize AirPlay functionality to stream audio directly from Apple devices. Note that AirPlay performance can be affected by network conditions.
- Мясцовыя СМІ: Прайграванне аўдыё files from USB-connected storage devices.
3. Шматзоннае аўдыё
When integrated with a Russound MCA system, the DMS-3.1 can provide multiple independent audio streams to different zones. Consult your MCA system manual for details on configuring and managing multi-zone audio.
Тэхнічнае абслугоўванне
1. Уборка
- Перад чысткай пераканайцеся, што прылада выключана і адключана ад сеткі.
- Выкарыстоўвайце мяккую, сухую тканіну для працірання вонкавых паверхняў.
- Не выкарыстоўвайце вадкія ачышчальнікі, аэразолі або абразіўныя матэрыялы, бо яны могуць пашкодзіць пакрыццё або ўнутраныя кампаненты.
2. Абнаўленне прашыўкі
- Periodically check the Russound support webсайт для новых версій прашыўкі.
- Firmware updates can improve performance, add new features, and resolve known issues.
- Follow the specific instructions provided with each firmware update package.
Ліквідацыю непаладак
| праблема | Магчымая прычына | Рашэнне |
|---|---|---|
| Няма ўлады | Power cable disconnected; outlet not active. | Пераканайцеся, што кабель харчавання надзейна падключаны. Праверце разетку з дапамогай іншай прылады. |
| Няма аўдыявыхаду | Incorrect audio connections; volume too low; input selection on receiver incorrect. | Verify all audio cables are correctly connected. Increase volume. Select the correct input on your audio system. |
| Streaming interruptions or buffering | Weak network connection; router issues; internet service provider (ISP) problems. |
|
| AirPlay is sporadic or not working | Wi-Fi interference; network congestion; outdated firmware. |
|
| Control app not connecting to DMS-3.1 | Control device not on same network; network issues; DMS-3.1 not powered on. | Ensure both devices are connected to the same local network. Restart the app and the DMS-3.1. Check network cables. |
Тэхнічныя характарыстыкі
| Марка | Русанд |
| Нумар мадэлі | 2450-533419 |
| Вытворца | Русанд |
| Сумяшчальныя прылады | Television, Laptop, Desktop, Tablet, Smartphone |
| Тып раздыма | HDMI, USB, RJ45 |
| Колер | Чырвоны |
| Тэхналогія цюнэра | Лічбавы |
| Тып цюнэра | Лічбавы |
| Analog Video Format | NTSC |
| Уключае пульт дыстанцыйнага кіравання | няма |
| Вага прадмета | 9.85 фунта |
| UPC | 013040003092, 612934533419 |
| ASIN | B007BS01ZS |
| GTIN | 013040003092, 612934533419 |
Гарантыя і падтрымка
Інфармацыя аб гарантыі
The Russound DMS-3.1 Network Player Digital Media Streamer comes with a 30-дзённая абмежаваная гарантыя. This warranty covers defects in materials and workmanship under normal use. Please retain your proof of purchase for warranty claims. For specific terms and conditions, refer to the warranty card included with your product or visit the official Russound webсайт.
Падтрымка кліентаў
For technical assistance, troubleshooting beyond this manual, or warranty service, please contact Russound customer support.
- Інтэрнэт-падтрымка: Visit the official Russound webсайт з часта задаванымі пытаннямі, дапаможнымі дакументамі і кантактнымі формамі.
- Падтрымка па тэлефоне: Refer to the Russound website for regional contact numbers and operating hours.
- When contacting support, please have your model number (2450-533419) and purchase date available.
