Bellman & Symfon Alarm Clock Visit (BE1580) User Manual

1. Уводзіны

The Bellman & Symfon Alarm Clock Visit (BE1580) is a digital alarm clock designed to provide a reliable and effective wake-up experience. It features a loud alarm, high-intensity flashing lights, and a powerful bed shaker. This alarm clock is also part of the Visit alerting system, allowing it to alert you to other important signals in your home, such as a doorbell, telephone, or fire alarm.

The large LCD display with adjustable backlight ensures clear visibility, and the battery backup feature maintains all functions during a power outage. The loud 100+dB ascending alarm spans multiple frequencies to ensure you wake up.

Image 1: Bellman & Symfon Alarm Clock Visit with its illuminated display.

2. Што ў скрынцы

Upon unboxing your Bellman & Symfon Alarm Clock Visit, you should find the following items:

• Bellman & Symfon Alarm Clock Visit (BE1580) unit
• Шэйкер для ложка
• Адаптар сілкавання
• Кіраўніцтва карыстальніка (на некалькіх мовах)

Image 2: The Bellman & Symfon Alarm Clock Visit packaging.

For a visual guide on unboxing, please refer to the 'Alarm Clock Classic How To Use Video' below (0:00-0:27).

3. Налада і пачатак працы

Follow these steps to set up your alarm clock:

1. Падключыце адаптар сілкавання: Plug the power adapter into a wall outlet, then connect the other end into the power port on the back of the alarm clock.
2. Connect the Bed Shaker: Plug the bed shaker into the designated port on the back of the alarm clock. Place the bed shaker under your pillow or mattress for optimal vibration.

Image 3: Proper placement of the bed shaker under a pillow.

For a visual guide on connecting the power adapter and bed shaker, please refer to the 'Alarm Clock Classic How To Use Video' above (0:29-0:42).

4. Усталёўка часу

To set the current time on your alarm clock:

1. Націсніце Time Setting button located on the left side of the alarm clock.
2. Rotate the button to adjust the гадзіны.
3. Press the button again, then rotate it to adjust the хвілін.
4. Press the button one more time to save your settings.

For a visual guide on setting the time, please refer to the 'Alarm Clock Classic How To Use Video' above (0:43-1:00).

5. Налада сігналізацыі

To set your desired wake-up alarm time:

1. Націсніце Alarm Setting button located on the right side of the alarm clock.
2. Rotate the button to adjust the гадзіны for your alarm.
3. Press the button again, then rotate it to adjust the хвілін for your alarm.
4. Press the button one more time to save your alarm settings.
5. Каб уключыць будзільнік, націсніце Alarm On/Off button on the top of the clock. A bell symbol will appear on the screen, indicating the alarm is active.

When the alarm triggers, it will sound, the bed shaker will vibrate, and the sound will gradually increase to 100 decibels across different frequencies.

For a visual guide on setting and activating the alarm, please refer to the 'Alarm Clock Classic How To Use Video' above (1:01-1:26).

6. Функцыя паўтору будзільніка

To temporarily silence the alarm and get a few more minutes of sleep:

• Калі прагучыць сігнал трывогі, націсніце Кнопка "Адкласці". on the top of the alarm clock.
• The smart snooze function will reduce the snooze time intervals from 9 minutes down to 2 minutes with each subsequent press.

Каб цалкам выключыць будзільнік, націсніце кнопку Alarm On/Off button. The bell symbol will disappear from the screen.

For a visual guide on using the snooze function, please refer to the 'Alarm Clock Classic How To Use Video' above (1:49-2:08).

7. Дадатковыя магчымасці

The Bellman & Symfon Alarm Clock Visit includes several additional features for enhanced usability:

• Дыммер: Located on the back of the alarm clock, the first button adjusts the brightness of the backlight in five steps, from low to high, including a permanent backlight option.
• Гук укл./выкл.: The second button on the back allows you to turn the alarm sound on or off when the alarm is triggered.
• 12/24-гадзінны фармат: The third button on the back switches the time display between 12-hour and 24-hour formats.

For a visual guide on these features, please refer to the 'Alarm Clock Classic How To Use Video' above (2:09-2:44).

8. Backup Batteries

The Alarm Clock Visit features a backup battery function to ensure it remains fully operational during a power outage. This means your alarm settings and time will be preserved, and the alarm will still function.

• Тып батарэі: The alarm clock uses 4 AAA Nickel-metal hydride (NiMH) 1.2V rechargeable batteries.
• Заўвага: Backup batteries are не ўключаны with the Alarm Clock Visit and must be purchased separately.
• Ўстаноўка: To install the batteries, remove the battery cover on the bottom of the alarm clock using a small screwdriver and insert the batteries according to the polarity markings.

If the battery symbol on the screen shows a cross, it indicates that the batteries are not installed or are not functioning correctly.

For a visual guide on backup battery installation, please refer to the 'Alarm Clock Classic How To Use Video' above (2:46-3:24).

9. Operating the Alarm Clock Visit

The Bellman & Symfon Alarm Clock Visit offers multiple ways to wake you up and keep you informed:

• Гучная сігналізацыя: The clock features an extra loud, audible alarm with an ascending 100+dB multiple frequency signal.
• High-Intensity Flash: Four super bright flashing LED lights provide a visual alert, similar to a smartphone camera flash. This is a great alternative to a sounding alarm.
• Powerful Bed Shaker: The included bed shaker wakes you up with strong vibrations, ideal for heavy sleepers or those with hearing loss. The bed shaker itself also emits a high sound.
• Night Light Beacon: A discreet blue light guides you back to bed if you are up at night.
• Visit Alerting System Integration: The Visit version of the alarm clock connects to the Bellman & Symfon Visit alerting system. It will alert you to important signals in your home, such as a baby crying, a doorbell ringing, a telephone call, or a fire alarm.

You can choose to be woken up by any combination of these methods (loud alarm, flashing light, strong vibration) or all three simultaneously.

10. Тэхнічнае абслугоўванне

To ensure the longevity and optimal performance of your Bellman & Symfon Alarm Clock Visit, follow these maintenance guidelines:

• Уборка: Wipe the alarm clock and bed shaker with a soft, dry cloth. Do not use liquid cleaners or abrasive materials.
• Размяшчэнне: Keep the alarm clock in a dry environment, away from direct sunlight, extreme temperatures, and moisture.
• Сыход за батарэяй: If using backup batteries, ensure they are rechargeable NiMH AAA 1.2V batteries. Replace them when their performance degrades.
• Кабельнае кіраванне: Ensure all cables (power adapter, bed shaker) are not kinked or pinched to prevent damage.

11. Выпраўленне непаладак

If you encounter any issues with your Bellman & Symfon Alarm Clock Visit, try the following troubleshooting steps:

• Гадзіннік не ўключаецца: Ensure the power adapter is securely plugged into both the wall outlet and the alarm clock. Check if the outlet is functional.
• Сігналізацыя не гучыць/не вібруе: Verify that the alarm time is set correctly and activated (bell symbol visible). Check the sound on/off setting on the back of the clock. Ensure the bed shaker is properly connected.
• Display not visible/too dim: Adjust the dimmer setting on the back of the clock.
• Battery symbol with a cross: This indicates that the backup batteries are either not installed or are not the correct type/voltage. Install 4 AAA NiMH 1.2V rechargeable batteries.
• Visit system alerts not working: Ensure your alarm clock is correctly linked to your Visit alerting system transmitters. Refer to the Visit system's specific instructions for pairing.

If the issue persists after attempting these steps, please contact Bellman & Symfon customer support.

12. Тэхнічныя характарыстыкі

13. Гарантыя і падтрымка

For warranty information, product registration, or technical support, please refer to the official Bellman & Symfon webсайт або звярніцеся непасрэдна ў службу падтрымкі кліентаў. Захоўвайце чэк аб куплі як пацвярджэнне пакупкі для любых гарантыйных прэтэнзій.

Кантактная інфармацыя: Калі ласка, наведайце www.bellman.com каб атрымаць найноўшыя рэсурсы падтрымкі і кантактную інфармацыю.
