AZDOME M300 1296P WiFi Dash Cam Instruction Manual

1. Уводзіны

The AZDOME M300 is a compact, monitor-less dash cam designed for easy installation and discreet operation. It features 1296P high-resolution recording, WiFi connectivity for smartphone control, and a super capacitor for enhanced durability and safety across a wide temperature range. This manual provides detailed instructions for installation, operation, and maintenance to ensure optimal performance of your device.

Figure 1: AZDOME M300 Dash Cam Overview

2. Асноўныя магчымасці

• 1296P High-Resolution Recording: Захоплівае празрыстую ежуtage of license plates and road signs.
• Падключэнне Wi-Fi: Connects to your smartphone via the dedicated AZDOME app for viewing, playback, downloading, and managing recordings.
• Суперкандэнсатар: Replaces traditional batteries for improved safety, rapid charging, and reliable operation in extreme temperatures (-20°C to 70°C).
• G-сэнсар: Automatically detects impacts and locks the current recording file to prevent overwriting, preserving critical accident evidence.
• цыклічны запіс: Continuously records by overwriting the oldest files when the memory card is full, ensuring uninterrupted recording.
• Кругласутачны маніторынг паркоўкі: Provides surveillance when your vehicle is parked (requires a separately purchased hardwire kit).
• Шырокі дынамічны дыяпазон (WDR): Enhances video quality in varying light conditions, ensuring clear images in both bright and dark areas.
• Начное бачанне: Equipped with an F1.8 aperture 6-layer lens for clear recording in low-light conditions.
• Кампактны і дыскрэтны дызайн: Monitor-less design minimizes obstruction to the driver's view and is inconspicuous in the vehicle.
• Лёгкая ўстаноўка: Mounts securely with double-sided tape, suitable for front or rear installation.

3. Настройка

3.1 Змест пакета

Перад устаноўкай пераканайцеся, што ўсе кампаненты наяўныя:

• Відэарэгістратар AZDOME M300
• Car Mount (with adhesive tape)
• Car Charger (USB)
• Кіраўніцтва карыстальніка
• Wiring Tool Kit
• Электрастатычная плёнка

Figure 2: AZDOME M300 Package Contents and Easy Installation

3.2 Устаўка карты MicroSD

Insert a MicroSD card (Class 10+ or U3, A2 speed, up to 128GB, not included) into the designated slot on the dash cam. Ensure the card is inserted correctly until it clicks into place.

3.3 Фізічная ўстаноўка

1. Ачысціце лабавое шкло, дзе вы плануеце ўсталяваць відэарэгістратар.
2. Apply the electrostatic film to the cleaned area on the windshield. This helps protect your windshield and makes removal easier.
3. Attach the dash cam mount with the double-sided tape to the electrostatic film. Ensure it is positioned to provide a clear view of the road without obstructing your driving vision. The camera's view can be adjusted by 90 degrees.
4. Connect the car charger to the dash cam and route the cable neatly along the windshield and dashboard to the car's power outlet (cigarette lighter socket). Use the provided wiring tool to tuck the cable.
5. The dash cam can be installed on either the front or rear windshield.

Figure 3: Flexible Installation for Front or Rear View

3.4 WiFi Connection and App Setup

The AZDOME M300 uses WiFi for smartphone connectivity via the AZDOME app. This allows you to control the device and manage recordings without a built-in monitor.

1. Спампаваць АЗДОМ праграму з App Store (iOS) або Google Play Store (Android).
2. Ensure the dash cam is powered on and the WiFi indicator light is blue. If not, press and hold the WiFi button for 3 seconds to activate/deactivate WiFi.
3. На вашым смартфоне перайдзіце па спасылцы Налады > Бесправадная бесправадная сетка (Wi-Fi) and connect to the WiFi network named "M300-****". The initial password is "12345678".
4. Once connected, open the AZDOME app. The main screen should display "M300".
5. Націсніце на "Real-time Screen" каб view жывы footage з відэарэгістратара.

Important Notes for WiFi Connection:

• Keep your smartphone within 3 meters of the dash cam for a stable connection.
• For iPhone users, ensure your system language is set to Japanese if experiencing connection issues.
• Grant "Location Information Permissions" to the AZDOME app during installation. If already installed, check app permissions in your phone settings.
• If connection issues persist, try turning off your smartphone's mobile data communication (Settings > AZDOME > Mobile Data Communication > OFF) or check your wireless data settings (Settings > Wireless Data > WLAN).

Figure 4: Connecting to the AZDOME App via WiFi

4. Аперацыя

4.1 Аўтаматычная запіс

The dash cam automatically starts recording when the vehicle's engine is turned on and stops when the engine is turned off. Recordings are saved in segments (e.g., a few minutes per file).

4.2 Запіс цыкла

When the MicroSD card is full, the loop recording function automatically overwrites the oldest unlocked video files to make space for new recordings. This ensures continuous recording without manual intervention.

4.3 Аварыйны запіс (G-сенсор)

The built-in G-sensor detects sudden shakes or impacts. When an event is detected, the dash cam automatically locks the current video file, preventing it from being overwritten by loop recording. These locked files are crucial evidence in case of an accident.

4.4 Запіс голасу

The dash cam supports voice recording. This feature can be enabled or disabled via the AZDOME app settings. Voice recordings can provide additional context for accident situations.

4.5 Маніторынг паркоўкі

For 24-hour parking monitoring, a separate hardwire kit (e.g., JYX04 Buck Line, ASIN: B09KPSBZNY) is required. When connected, the dash cam can monitor your vehicle for impacts or motion even when parked, providing protection against hit-and-runs or vandalism.

Figure 5: 24-Hour Parking Monitoring

4.6 App Functions (View, Playback, Download, Share)

Using the AZDOME app connected via WiFi:

• У рэжыме рэальнага часу View: See what the dash cam is recording live on your smartphone.
• Прайграванне: Access and play recorded video files directly from the dash cam.
• Спампаваць: Save important video files from the dash cam to your smartphone.
• падзяліцца: Easily share downloaded videos with family and friends via social media.

Video 1: AZDOME M300 Dash Cam Features Overview. This video demonstrates the compact design, easy installation, WiFi connectivity, 1296P recording, loop recording, and G-sensor functionality.

5. Тэхнічнае абслугоўванне

5.1 Кіраванне картамі MicroSD

To ensure optimal performance and prevent recording errors, it is recommended to format the MicroSD card regularly (e.g., once a month) using the AZDOME app. This helps maintain the card's health and prevents data corruption.

5.2 Ачыстка прылады

Wipe the dash cam lens and body with a soft, dry cloth to remove dust and smudges. Avoid using abrasive cleaners or solvents that could damage the device.

6. Выпраўленне непаладак

6.1 Праблемы з падключэннем да Wi-Fi

• Cannot connect to M300-**** WiFi: Ensure the dash cam's WiFi indicator is blue. If not, long-press the WiFi button for 3 seconds. Keep your phone within 3 meters of the dash cam.
• App not displaying real-time screen: For iPhones, ensure the system language is set to Japanese. Verify that the AZDOME app has "Location Information Permissions" enabled. Try reinstalling the app. In phone settings, try turning off "Mobile Data Communication" for the AZDOME app or check "Wireless Data" settings.

6.2 Recording Errors or Poor Quality

• Recording misses or corrupted files: Ensure you are using a genuine MicroSD card with a write speed of Class 10+ or U3, A2. Lower quality or slower cards can cause issues. Try formatting the SD card.
• Image quality not as expected: The dash cam records in 1296P. If you changed the resolution to 1080P, revert it to 1296P for higher quality.

6.3 Playback Issues

• Slow playback or freezing: Try turning off Bluetooth on your smartphone during playback to avoid potential interference.

6.4 Power Cable Length

The included power cable is designed for front installation. If installing the dash cam in the rear, you may need to purchase a longer USB power cable or an extension.

7. Тэхнічныя характарыстыкі

8. Гарантыя і падтрымка

8.1 Гарантыя на выраб

The AZDOME M300 comes with a Гарантыя 1 год з даты пакупкі. Гэтая гарантыя распаўсюджваецца на вытворчыя дэфекты і забяспечвае надзейную працу вашай прылады.

8.2 Падтрымка кліентаў

For any questions, concerns, or technical assistance regarding your AZDOME M300 dash cam, please do not hesitate to contact us. Our support team is available to provide prompt assistance.

Спосабы сувязі:

• Via Amazon messaging service.
• Via Email (refer to product packaging or official AZDOME website for email address).

Note: LINE support has been discontinued. Please use Amazon or email for all inquiries.
