YESKAMO 4MP Wireless Outdoor Battery Security Camera System

1. Уводзіны

Thank you for choosing the YESKAMO 4MP Wireless Outdoor Battery Security Camera System. This manual provides detailed instructions for the installation, operation, and maintenance of your security camera system. Please read this manual thoroughly before use and retain it for future reference.

2. Інфармацыя па бяспецы

• Перад пачаткам працы пераканайцеся, што ўсе падключэнні харчавання надзейныя і правільныя.
• Do not expose the camera or base station to extreme temperatures, humidity, or corrosive environments.
• Avoid placing the camera in direct sunlight for prolonged periods if not equipped with a solar panel.
• Захоўвайце прыладу далей ад дзяцей і хатніх жывёл.
• Use only manufacturer-approved accessories and power adapters.
• Не спрабуйце разбіраць або мадыфікаваць прыладу, бо гэта прывядзе да анулявання гарантыі.

3. Змесціва ўпакоўкі

Калі ласка, праверце ўпакоўку на наяўнасць наступных прадметаў:

• YESKAMO 4MP Battery Cameras (x2)
• Базавая станцыя (x1)
• Мантажныя кранштэйны і шрубы
• USB-кабель для зарадкі
• Адаптар харчавання для базавай станцыі
• Кабель Ethernet
• Кіраўніцтва карыстальніка

Note: Solar panels and SD cards are sold separately.

4. Прадукт скончыўсяview

4.1 Кампаненты камеры

The YESKAMO camera is designed for both indoor and outdoor use, featuring a robust, weather-resistant build.

Image 4.1: YESKAMO 4MP Wireless Outdoor Battery Security Camera

• Аб'ектыў: 4MP UHD resolution for clear video.
• ВК-святлодыёды: For infrared night vision.
• Пражэктары: Enable color night vision and act as deterrents.
• Датчык PIR: Passive Infrared sensor for motion detection.
• Мікрафон і дынамік: Для двухбаковай гукавой сувязі.
• Антэна: 4 dBi external antenna for enhanced Wi-Fi signal.
• Кропка мацавання: Для бяспечнай усталёўкі.

4.2 Base Station Components

The base station acts as the central hub for your cameras, managing recordings and network connectivity.

Image 4.2: YESKAMO Base Station and Camera

• Слот для SD-карты: Падтрымлівае да 128 ГБ для лакальнага захоўвання.
• Порт USB: For potential future expansions or accessories.
• Ethernet порт: Для падлучэння да правадной сеткі.
• Спажываная магутнасць: Для падлучэння адаптара сілкавання.
• QR-код: Used for initial setup and pairing with the app.

5. Настройка

5.1 Загрузка праграмы і рэгістрацыя ўліковага запісу

1. Спампаваць Eseecloud or ЕСКАМО праграму з крамы праграм вашага смартфона (iOS або Android).
2. Адкрыйце праграму і зарэгіструйце новы ўліковы запіс або ўвайдзіце ў сістэму, калі ён у вас ужо ёсць.

5.2 Pairing Cameras with the Base Station

The system is designed for easy, two-step activation:

1. In the app, select to add a new device and scan the QR code located on the base station.
2. Power on the camera(s). The camera(s) will automatically connect to the base station.
3. Once connected, you can name your cameras and configure initial settings within the app.

5.3 Фізічная ўстаноўка

The cameras are designed for wall mounting. Choose a location that provides the desired viewing angle and is within Wi-Fi range of the base station. If using a solar panel (sold separately), ensure the camera is placed where it receives at least 2 hours of direct sunlight daily.

• Use the provided mounting bracket and screws to securely attach the camera to a wall or suitable surface.
• Адрэгулюйце кут камеры, каб ахапіць патрэбную зону маніторынгу.

6. Operating the Camera System

6.1 У прамым эфіры View і двухбаковае аўдыё

Access live video feeds from your cameras through the Eseecloud/YESKAMO app on your smartphone, PC, or tablet. The integrated microphone and speaker allow for real-time two-way communication.

Image 6.1: Two-Way Audio Communication

6.2 Дэтэктар руху

The camera features AI algorithms for human recognition, achieving up to 99% accuracy, and PIR motion detection to reduce false alerts.

Image 6.2: Smart PIR Motion Detection

• Выяўленне чалавека AI: Focuses on human shapes to minimize alerts from animals or inanimate objects.
• Рэгуляваная адчувальнасць: Customize motion detection sensitivity in the app.
• Рэжымы абвесткі: The camera's two spotlights and siren offer three customizable alert modes.

6.3 Начное бачанне

Камера забяспечвае выразнае відэаназіранне нават пры слабым асвятленні.

Image 6.3: 4MP Clear Colorful Night Vision

• Каляровы начны бачанне: Enabled by the two integrated spotlights, providing detailed, full-color video at night.
• Інфрачырвонае начное бачанне: Standard black and white night vision when spotlights are off.

6.4 Запіс і захоўванне

Your camera system offers flexible storage options for recorded footage.

Image 6.4: Cloud and SD Card Storage Options

• Лакальнае сховішча: The base station supports a Micro SD card up to 128GB (not included).
• Воблачнае сховішча: 1 year of free cloud storage is offered (registration required).

6.5 Падключэнне да Wi-Fi

The system utilizes 2.4 GHz Wi-Fi for stable and extended coverage.

• 100% Wireless: Cameras connect wirelessly to the base station.
• Пашыраны дыяпазон: The upgraded 4 dBi external antenna provides a stronger signal through walls and up to 91.4 meters (300 feet) of Wi-Fi coverage.
• Толькі 2.4 ГГц: The system supports 2.4 GHz Wi-Fi networks only; 5 GHz is not supported.

7. Тэхнічнае абслугоўванне

7.1 Кіраванне батарэяй

The cameras are equipped with long-lasting batteries.

• Тэрмін службы батарэі: Provides up to 180 days of continuous protection on a full charge.
• Сонечная зарадка: Supports charging via a compatible solar panel (sold separately). Approximately 2 hours of direct sunlight can provide enough power for one day of operation. With consistent solar charging, the camera can operate for up to 360 days without manual recharging.

7.2 Устойлівасць да ўздзеяння надвор'я

The cameras have an IP67 waterproof rating, making them suitable for various outdoor weather conditions.

7.3 Ачыстка

Periodically clean the camera lens and housing with a soft, dry cloth to ensure optimal image quality and prevent debris buildup.

8. Выпраўленне непаладак

• Камера не падключаецца: Ensure the base station is powered on and connected to the internet. Verify the camera is powered on and within range. Re-scan the QR code on the base station via the app.
• Poor Wi-Fi Signal: Ensure the base station is centrally located. Avoid placing it near large metal objects or other sources of interference. The camera's external antenna helps improve signal strength.
• Абвесткі аб ілжывым руху: Adjust the motion detection sensitivity in the app. Utilize AI human detection to filter out non-human movements.
• Кароткі тэрмін службы батарэі: Ensure the camera is fully charged. If using a solar panel, verify it receives adequate direct sunlight daily. Extreme cold temperatures can affect battery performance.
• Няма начнога бачання: Check if the IR LEDs or spotlights are obstructed. Ensure night vision settings are enabled in the app.

9. Тэхнічныя характарыстыкі

10. Гарантыя і падтрымка

The YESKAMO 4MP Wireless Outdoor Battery Security Camera System comes with a one-year free warranty from the date of purchase.

If you encounter any issues or have questions regarding your product, please do not hesitate to contact our support team. Our dedicated team is available to assist you with troubleshooting, technical guidance, and any warranty-related inquiries.

Кантактная інфармацыя: Please refer to the contact details provided on the product packaging or the official YESKAMO webсайт для атрымання найбольш актуальнай інфармацыі аб падтрымцы.
