1. Уводзіны
Thank you for choosing Ollny Christmas Lights. This manual provides essential information for the safe and effective use of your 200LED 60FT Warm White String Lights. Designed for both indoor and outdoor applications, these lights feature multiple lighting modes, a convenient timer, and a connectable design for extended coverage.
Image 1: Ollny 200LED 60FT Warm White String Lights, coiled with power adapter.
2. Важныя інструкцыі па бяспецы
- Прачытайце ўсе інструкцыі перад выкарыстаннем.
- Do not connect the lights to the power supply while they are in the packaging.
- Ensure the power adapter is protected from direct water exposure when used outdoors. The lights themselves are IP44 waterproof, but the adapter requires protection.
- Do not attempt to replace individual LEDs. The entire string is designed as a sealed unit.
- Захоўваць удалечыні ад крыніц цяпла і адкрытага агню.
- Always unplug the lights from the power source before installation, removal, or maintenance.
- Use only the provided power adapter. Using a different adapter may damage the product or pose a safety risk.
- Гэты прадукт не з'яўляецца цацкай. Захоўваць у месцах, недаступных дзецям.
3. Змесціва ўпакоўкі
Праверце наяўнасць і спраўнасць усіх кампанентаў:
- 1 x Ollny 200LED 60FT Warm White String Light
- 1 x Power Adapter with Controller
4. Інструкцыі па ўсталёўцы
4.1 Распакоўка і падрыхтоўка
- Carefully remove the string lights from the packaging. It is recommended to uncoil them slowly to prevent tangling.
- Inspect the entire length of the string lights and the power adapter for any signs of damage. Do not use if damaged.
- Determine your desired installation location, ensuring it is within reach of a power outlet.
4.2 Connecting Multiple Sets (Optional)
These lights are designed to be connectable, allowing you to extend the length for larger areas. You can connect up to 3 sets of Ollny 200LED 60FT string lights together, all controlled by a single power adapter and controller.
- Locate the male and female connectors at the ends of each string light set.
- Align the connectors and firmly push them together.
- Twist the waterproof cap on the connector to secure the connection and ensure water resistance.
- Connect the first string light set to the power adapter.
Image 2: Illustration of connecting multiple string light sets.
4.3 Ўстаноўка
Hang or drape the lights in your desired location. The flexible wire allows for creative placement around objects, along walls, or across ceilings.
Video 1: Demonstration of Ollny Christmas Lights 200LED 60FT Indoor/Outdoor setup and display.
5. Інструкцыя па эксплуатацыі
5.1 Уключэнне/выключэнне
Plug the power adapter into a standard electrical outlet. The lights will illuminate in the last selected mode due to the memory function.
5.2 рэжымаў асвятлення
The integrated controller on the power adapter allows you to cycle through 8 different lighting modes. Short press the button on the controller to switch between modes:
- Камбінацыя: Cycles through all modes.
- У хвалях: Lights fade in and out in a wave-like pattern.
- Паслядоўны: Lights illuminate in sequence.
- Slo-Glo: Lights slowly glow on and off.
- Chasing/Flash: Lights chase and flash.
- Павольнае згасанне: Lights slowly fade in and out.
- Мігаценне/ўспышка: Lights twinkle and flash.
- Пастаянна гарыць: Lights remain continuously lit.
Image 3: Controller for selecting 8 lighting modes.
5.3 Функцыя таймера
To activate the timer function, long press the button on the controller. The lights will then operate on a 6-hour ON and 18-hour OFF cycle. The timer will automatically repeat daily until manually deactivated.
Image 4: Timer function for 6 hours ON, 18 hours OFF.
5.4 Функцыя памяці
The lights are equipped with a memory chip that saves your last selected lighting mode and timer setting. When powered on again, the lights will resume the previous setting without needing to be reset.
6. Тэхнічнае абслугоўванне
6.1 Ачыстка
Ensure the lights are unplugged before cleaning. Wipe the lights gently with a soft, dry cloth. Do not use harsh chemicals or abrasive cleaners.
6.2 Захоўванне
When not in use, carefully coil the string lights and secure them to prevent tangling. Store them in a cool, dry place away from direct sunlight and extreme temperatures.
7. Выпраўленне непаладак
| праблема | Магчымая прычына | Рашэнне |
|---|---|---|
| Святло не гарыць. | Адсутнічае сілкаванне або дрэннае злучэнне. | Ensure the power adapter is securely plugged into a working outlet. Check all connections between light sets. |
| Святло цьмянае або міргае. | Insufficient power or damaged section. | Ensure no more than 3 sets are connected. Inspect the string for any visible damage. |
| Функцыя таймера не працуе. | Timer not activated correctly. | Long press the controller button to activate the 6H ON/18H OFF timer. |
| Lights are tangled. | Improper unpacking or storage. | Carefully untangle the lights. For future use, uncoil slowly and store neatly. |
8. Тэхнічныя характарыстыкі
- Нумар мадэлі: HG-29V220C
- Светлы колер: Цёплы белы (2800 Кельвінаў)
- Колькасць святлодыёдаў: 200
- Даўжыня прадмета: 60 футаў
- Выкарыстанне ў памяшканні/на вуліцы: Outdoor (IP44 Waterproof)
- Крыніца харчавання: Правадная электрычная
- Ватtage: 6 ват
- тtage: 29 В (нізкі ўзровень гучнасціtage, Safe to Touch)
- матэрыял: Медзь, пластык
- Тып кантролера: Кіраванне кнопкамі
- Асаблівасці: 8 Lighting Modes, Timer (6H ON/18H OFF), Memory Function, Connectable (up to 3 sets)
- вытворца: Linhai Hengguang Lighting Ltd
- Вага прадмета: 11.7 унцыі
Відэа 2: Скончанаview of Ollny Outdoor String Lights in Warm White.
9. Гарантыя і падтрымка
For warranty information, technical support, or any questions regarding your Ollny Christmas Lights, please refer to the product packaging or contact Ollny customer service directly. Contact details are typically available on the manufacturer's webсайт або праз вашу платформу для пакупак.
