ZWP XRS551-D

ZWP XRS551-D Replacement Remote Control User Manual

Model: XRS551-D

1. Уводзіны

This manual provides instructions for the ZWP XRS551-D replacement remote control. This remote is designed to operate various Vizio Soundbar models, offering a direct replacement experience without the need for complex programming.

ZWP XRS551-D Replacement Remote Control

Выява: спераду view of the ZWP XRS551-D replacement remote control, showcasing яго размяшчэнне кнопак.

1.1 Compatible Soundbar Models

The ZWP XRS551-D remote control is compatible with the following Vizio Soundbar models:

  • SB3531-D0
  • SB3621N-E8
  • SB3651-E6
  • SB3651E6
  • SB3820-C6
  • SB3851-D0
  • SB4031-D5
  • SB4051-D5
  • SB351-D0

The remote control is constructed from high-quality ABS material, ensuring durability and a comfortable grip. It features an ergonomic design for ease of use and quick response times.

Smart and Quality Features of ZWP XRS551-D Remote

Image: A graphic highlighting the ZWP XRS551-D remote control's smart and quality features, including stable link, 0.2-second fast response, easy grip and control, and power-saving capabilities.

2. Настройка

2.1 Устаноўка батарэі

Для пульта дыстанцыйнага кіравання патрэбныя дзве батарэйкі тыпу AAA (не ўключаны ў камплект). Каб усталяваць іх, выканайце наступныя дзеянні:

  1. Знайдзіце батарэйны адсек на задняй частцы пульта дыстанцыйнага кіравання.
  2. Зрушыце вечка батарэйнага адсека ўніз, каб адкрыць яго.
  3. Устаўце дзве батарэйкі тыпу ААА, сочачы за правільнай палярнасцю (+ і -), як паказана ўнутры адсека.
  4. Адсуньце крышку батарэйнага адсека на месца, пакуль яна не зашчоўкнецца.
Battery installation for ZWP XRS551-D Remote

Малюнак: А view of the back of the ZWP XRS551-D remote control with the battery cover removed, showing the battery compartment and the correct orientation for inserting two AAA batteries. Two AAA batteries are depicted next to the remote, with a red 'X' over them to indicate they are not included. The image also highlights an ultra-long standby time of up to 6 months.

2.2 Першапачатковае выкарыстанне

No programming is required. Once batteries are installed, the remote control is ready for immediate use with compatible Vizio Soundbar models. Simply point the remote towards your soundbar and begin operation.

ZWP XRS551-D Remote Control - No Setup Required

Image: A hand holding the ZWP XRS551-D remote control, with text indicating "Perfectly Compatible" and "No Setup Required," illustrating the ease of initial use.

3. Інструкцыя па эксплуатацыі

3.1 Асноўныя функцыі

The remote control provides standard functions for your Vizio Soundbar. Familiarize yourself with the button layout for optimal control:

  • Кнопка харчавання: Уключае або выключае гукавую панэль.
  • Павялічыць/паменшыць гучнасць: Adjusts the soundbar's volume level.
  • Кнопка адключэння: Уключае або выключае гук саўндбара.
  • Кнопка ўводу: Cycles through available audio inputs (e.g., HDMI, Optical, Bluetooth).
  • Кнопка меню: Accesses the soundbar's menu options for settings adjustments.
  • Кнопкі навігацыі (Уверх/Уніз/Улева/Управа/ОК): Выкарыстоўваецца для навігацыі па меню і выбару.
  • Play/Pause, Skip Forward/Backward: Controls media playback when applicable (e.g., Bluetooth audio).

3.2 Remote Control Range and Angle

The remote operates using infrared (IR) technology. Ensure a clear line of sight between the remote control and the soundbar's IR receiver for optimal performance. The maximum effective range is approximately 10 meters (26 feet). It supports multi-angle induction up to 120 degrees, allowing for flexible positioning.

ZWP XRS551-D Remote Control Multi-Angle Induction and Range

Image: An illustration demonstrating the ZWP XRS551-D remote control's operational range and angle. It shows the remote functioning effectively up to 26 feet and at angles up to 120 degrees.

4. Тэхнічнае абслугоўванне

4.1 Ачыстка

To clean the remote control, wipe it with a soft, dry cloth. Do not use liquid cleaners, solvents, or abrasive materials, as these may damage the surface or internal components.

4.2 Замена батарэі

Replace batteries when the remote control's responsiveness decreases or it stops functioning. Always replace both AAA batteries simultaneously with new ones. Do not mix old and new batteries or different battery types, as this can lead to improper operation or battery leakage.

4.3 Захоўванне

Калі пульт дыстанцыйнага кіравання не будзе выкарыстоўвацца працяглы час, выміце батарэйкі, каб прадухіліць уцечку і магчымае пашкоджанне прылады. Захоўвайце пульт у прахалодным, сухім месцы, удалечыні ад прамых сонечных прамянёў і экстрэмальных тэмператур.

5. Выпраўленне непаладак

5.1 Пульт не адказвае

  • Праверце батарэі: Ensure batteries are inserted correctly with the proper polarity (+ and -). Replace with fresh AAA batteries if necessary.
  • Лінія візавання: Verify there are no obstructions between the remote control and the soundbar's IR receiver.
  • Адлегласць: Ensure you are within the effective operating range (approximately 10 meters or 26 feet).
  • Магутнасць саўндбара: Confirm the soundbar is powered on and functioning correctly.

5.2 Перарывістая функцыянальнасць

  • Узровень батарэі: Low batteries can cause inconsistent performance. Replace them with fresh ones.
  • Перашкоды: Strong light sources (e.g., direct sunlight, fluorescent lights) or other infrared devices might interfere with the remote's signal. Try operating the remote in a different environment or adjusting lighting conditions.

6. Тэхнічныя характарыстыкі

6.1 Агульныя

  • мадэль: XRS551-D
  • Марка: ЗВП
  • колер: Чорны
  • матэрыял: Высокаякасны АБС
  • Тэхналогія падключэння: Інфрачырвоны (ВК)
  • Тып кантролера: Кіраванне кнопкамі
  • Максімальная колькасць падтрымоўваных прылад: 1 (Soundbar)

6.2 Магутнасць

  • Тып батарэі: 2 х AAA (рэкамендуюцца шчолачныя, не ўключаны)
  • Час чакання: Up to 6 months (approximate, with fresh batteries)

6.3 Памеры і вага

  • Даўжыня: 7.28 цаляў (18.49 см)
  • Шырыня: 1.92 цаляў (4.88 см)
  • Рост: 1.02 цаляў (2.59 см)
  • Вага прадмета: 2.4 унцыі (68 грам)
ZWP XRS551-D Remote Control Ergonomic Design and Dimensions

Image: A visual representation of the ZWP XRS551-D remote control highlighting its ergonomic design and precise dimensions: Length 7.28 inches, Width 1.92 inches, and Height 1.02 inches.

7. Гарантыя і падтрымка

The ZWP XRS551-D remote control is manufactured with high-quality materials and undergoes quality assurance checks to ensure reliable performance. For any questions, technical assistance, or support inquiries, please contact the seller directly through your purchase platform.

Information regarding specific warranty terms and conditions may be available from your point of purchase or by contacting the seller.
