Plaud NotePin S AI Voice Recorder User Manual

1. Прадукт скончыўсяview

The Plaud NotePin S is a compact, wearable AI voice recorder designed to streamline note-taking and information management. It integrates advanced AI technology for transcription, summarization, and task list generation across 112 languages. The device offers multiple wearing options for convenience and features a simple one-press operation for recording.

Figure 1: Plaud NotePin S AI Voice Recorder

The Plaud NotePin S is equipped with two high-fidelity microphones for HD recordings and a 270mAh battery providing up to 20 hours of continuous use. It includes 64GB of internal memory and offers unlimited free cloud storage for recordings, transcriptions, and summaries, ensuring data security through top-tier encryption.

2. Настройка

2.1 Змест пакета

Verify that all items are present in your Plaud NotePin S package:

• 1 Plaud NotePin Voice Recorder
• 1 Black Lanyard
• 1 White Wristband
• 1 Silver Clip
• 1 Зарадная док-станцыя
• 1 кабель USB-C

2.2 Першапачатковая зарадка

Before first use, fully charge your Plaud NotePin S. Connect the USB-C cable to the charging dock, then connect the other end to a power source. Place the NotePin S onto the charging dock. The device's indicator light will show charging status and turn off when fully charged. A full charge typically provides 20 hours of continuous recording.

2.3 Уключэнне/выключэнне сілкавання

• Каб уключыць: Націсніце і ўтрымлівайце кнопку харчавання, пакуль не загарыцца індыкатар.
• Каб выключыць: Націсніце і ўтрымлівайце кнопку харчавання, пакуль не пагасне індыкатар.

2.4 Усталёўка праграмы і спалучэнне прылад

Download the official Plaud App from your device's app store. Follow the in-app instructions to create an account and pair your NotePin S via Bluetooth 5.0. This connection is essential for managing recordings, accessing AI features, and configuring device settings.

2.5 варыянтаў нашэння

The Plaud NotePin S offers four versatile wearing options:

• Magnetic Pin: Attach the device securely to clothing using the magnetic pin.
• Шыйны рэмень: Use the black lanyard for hands-free carrying around your neck.
• Браслет: Secure the device to your wrist with the white wristband for easy access.
• Кліп: Utilize the silver clip to attach the device to pockets, notebooks, or other surfaces.

3. Інструкцыя па эксплуатацыі

3.1 Запіс аўдыя

The Plaud NotePin S features a simple one-press operation:

• Каб пачаць запіс: Press the main button once. The indicator light will confirm recording has begun.
• Каб спыніць запіс: Press the main button once again. The indicator light will change to indicate recording has stopped.

Recordings are stored on the device's 64GB internal memory and automatically sync to the cloud via the Plaud App when connected.

3.2 Highlighting Key Moments

During a recording, you can mark important sections for easy retrieval:

• Highlight Button: Press the dedicated highlight button on the device to mark a specific moment in the audio. These highlights will be timestamped in the transcription.

3.3 Capturing Images and Text

The Plaud App and Web portal allow for multimodal input, combining audio with visual and textual notes:

• Захоп выявы: Within the app, you can snap photos of whiteboards, documents, or presentations. These images are timestamped and linked to the corresponding audio segment.
• Увод тэксту: Type additional notes or thoughts directly into the app, which will also be linked to the audio timeline.

3.4 Accessing Recordings and AI Features (Plaud App/Web)

All recordings and associated data are accessible through the Plaud App on your smartphone or the Plaud Web portal on your computer. The platform offers:

• Транскрыпцыя: Powered by GPT-4o and Claude 3.5 Sonnet, the app provides fast and accurate transcriptions in 112 languages, with speaker labels and custom vocabulary support.
• Падвядзенне вынікаў: Generate intelligent summaries, meeting minutes, and to-do lists from your recordings.
• Арганізацыя: Easily manage, organize, and share audio files, transcriptions, and summaries.

3.5 Asking Plaud (AI Query)

Utilize the 'Ask Plaud' feature within the app or web portal to query your recorded content. This allows you to get specific answers, generate insights, and retrieve information based on your notes and conversations.

3.6 AutoFlow

Configure AutoFlow settings in the Plaud App to automate tasks. For example, you can set up rules to automatically transcribe and summarize new recordings upon sync, or send email notifications with summaries to team members.

4. Тэхнічнае абслугоўванне

4.1 Ачыстка

Gently wipe the device with a soft, dry, lint-free cloth. Avoid using harsh chemicals, cleaning solvents, or abrasive materials, as these can damage the device's finish or internal components.

4.2 Сыход за акумулятарам

To maximize battery life, avoid exposing the device to extreme temperatures. Charge the device regularly, but do not leave it fully discharged for extended periods. The 270mAh battery is designed for long-term use.

4.3 Абнаўленне праграмнага забеспячэння

Regularly check for and install software updates via the Plaud App. Updates often include performance improvements, new features, and security enhancements.

5. Выпраўленне непаладак

5.1 Прылада не ўключаецца

• Ensure the device is fully charged. Connect it to the charging dock and a power source for at least 30 minutes.
• Паспрабуйце націснуць і ўтрымліваць кнопку харчавання даўжэйшы час (5-10 секунд).

5.2 Праблемы са спалучэннем

• Make sure Bluetooth is enabled on your smartphone and the Plaud NotePin S is powered on.
• Ensure the device is within range of your smartphone.
• Restart both your smartphone and the Plaud NotePin S.
• If previously paired, try unpairing and re-pairing the device through your phone's Bluetooth settings and the Plaud App.

5.3 Poor Recording Quality

• Пераканайцеся, што мікрафоны нічым не перакрываюцца.
• Запісвайце ў ціхім асяроддзі, каб мінімізаваць фонавы шум.
• Position the device optimally to capture audio from speakers.

5.4 Transcription Inaccuracies

• Verify that the correct audio language is selected in the Plaud App.
• Ensure clear audio input with minimal background noise.
• Utilize the custom vocabulary feature in the Plaud App for specialized terminology.

6. Тэхнічныя характарыстыкі

7. Гарантыя і падтрымка

For warranty information, technical support, or service inquiries, please refer to the official Plaud website or contact Plaud customer service directly. Keep your purchase receipt for warranty claims.
