JOUNJIP Single-Sided Keyless Entry Door Lock

Прадукт скончаныview

The JOUNJIP Single-Sided Keyless Entry Door Lock is a 100% mechanical solution, operating without keys, batteries, power, or wiring. This design eliminates the need for physical keys and provides reliable access control for various applications, including entry doors, fence gates, pool gates, and storage areas. The lock features a durable construction with a matte black finish and an upgraded square spindle for improved installation and performance.

• Механічныя аперацыі: No batteries, wiring, or external power required.
• Палепшаная бяспека: Bump key proof design with no keyhole to tampэр с.
• Square Spindle Design: Improved installation and durability for doors 1 3/8" to 2 3/8" thick.
• Рэжым праходжання: Allows temporary free access without requiring a code.
• Code Options: Features a drop pin code design with over 3500 possible combinations, supporting codes up to 9 digits in any order.
• Устойлівы да надвор'я: Suitable for outdoor use (not salt water proof).

Змест пакета

Перад пачаткам усталёўкі пераканайцеся, што ўсе кампаненты наяўныя:

• 1 Keypad + Lever Handle (Primary)
• 1 Inside Keypad Body (Secondary)
• 1 Square Spindle
• 2 Latch Size Options (2 3/8" Backset and 2 3/4" Backset)
• 8 Extra Code Change Pins + Springs + Tweezers
• Latch Plate and Strike Plate Set
• Stainless Steel Screws + 2 Extension Posts + Guide Sleeves
• 1 Ушчыльненне дзвярэй
• Шаблон ўстаноўкі

Figure 1: List of Parts for JOUNJIP Lock Model 101SQ-BL

Important Pre-Installation Checks

Перад пакупкайasing or installing, ensure your door meets the following criteria:

• Таўшчыня дзвярэй: Compatible with doors from 1 3/8" to 2 3/8" thick.
• Край дзвярэй: Must be installed on a flat, centered door edge. Not compatible with recessed doors or offset latch holes.
• афармленне: Requires a minimum of 6.5 inches of clearance from the center of the bore hole to the door frame to allow for the lever handle.
• Bore Hole: Designed for standard bore holes (2 1/8") which will be covered by the 2 1/2" black seal.

Figure 2: Door Compatibility Check

Figure 3: Minimum Clearance Requirement (6.5 inches)

Figure 4: Standard Bore Hole Dimensions

Інструкцыя па ўстаноўцы

Follow these steps carefully for proper installation of your JOUNJIP Single-Sided Keyless Entry Door Lock. For a visual guide, refer to the installation video below.

1. Падрыхтуйце замак:
   • Locate the code card provided with your lock and set it aside. This card contains the factory preset code.
   • If necessary, change the orientation of the lever handle on the primary keypad. Remove the screw holding the lever handle, orient the handle so it points towards the door hinges, then reinsert and tighten the screw.
2. Падрыхтуйце дзверы:
   • Measure the backset of your door (typically 2 3/8" or 2 3/4").
   • Refer to the provided installation template. Find the correct backset line on the template and fold it along that line.
   • Line up the center line of the template with the center of your door's latch hole.
   • Securely tape the template to the door.
   • Drill the top hole as indicated on the template.
3. Усталюйце зашчапку:
   • Устаўце зашчапку ў край дзвярэй.
   • Secure the latch with the provided screws.
4. Assemble the Keypad and Spindle:
   • Screw the extension posts into the primary keypad.
   • Tighten the extension posts using the provided wrench.
   • Attach the back seal to the primary keypad.
   • Use painter's tape to temporarily hold the back seal and keypad together for easier installation.
   • Insert the square spindle into the primary keypad.
5. Усталюйце замак:
   • Slide the spindle through the opening in the latch mechanism.
   • From the inside of the door, insert the spindle into the secondary keypad body.
   • Ensure both keypads are lined up with each other and flush against the door.
   • Select the proper screw length based on your door thickness (refer to the chart below).
   • Install the screws into the extension posts to secure the secondary keypad to the primary keypad.
6. Фінальны тэст:
   • Test the keypad function by entering the factory preset code (from your code card) and operating the lever handle.

Figure 5: Screw Selection Guide based on Door Thickness

Setting and Changing the Code

Your JOUNJIP lock uses a mechanical drop pin system for its code. The factory preset code is provided on a card in your package. You can change this code using the included tweezers and extra code change pins.

• The lock supports codes with up to 9 digits.
• The order of the digits in your code does not matter. For example, if your code is 1-2-3-4, then 4-3-2-1 or 1-4-2-3 will also unlock the latch.
• To change the code, refer to the detailed instructions provided in the physical manual included with your product. This process typically involves removing the back panel of the keypad and repositioning the internal pins.

Кіраванне клавіятурай

Before entering your code, always press the "C" (Clear) button. This resets all buttons mechanically, ensuring a clean entry for your code.

Figure 6: Pressing the "C" Button

Рэжым праходжання

The lock includes a convenient "Passage Mode" function. This allows you to temporarily set up free access, meaning the door can be opened without entering a code. This is useful for periods when frequent entry and exit are needed, such as during a party or when moving groceries. Refer to your physical manual for instructions on how to activate and deactivate Passage Mode.

Тэхнічнае абслугоўванне

To ensure the longevity and smooth operation of your JOUNJIP Keyless Entry Door Lock, regular maintenance is recommended:

• Уборка: Periodically wipe down the exterior of the lock with a soft, damp cloth to remove dust and grime. Avoid abrasive cleaners or solvents. For outdoor installations, a gentle spray with water and wiping dry can help maintain appearance.
• змазка: If the lever handle or internal mechanism feels stiff, apply a small amount of graphite lubricant (powdered graphite) to the moving parts. Do not use oil-based lubricants as they can attract dirt and dust.
• Шчыльнасць шруб: Occasionally check that all mounting screws are securely tightened. Loose screws can affect the lock's performance and security.

Ліквідацыю непаладак

If you encounter issues with your lock, consider the following common solutions:

• Код не працуе:
  • Ensure you are pressing the "C" button before entering your code.
  • Verify that you are using the correct code. Remember that the order of digits does not matter.
  • Check if any buttons are stuck or not fully depressing.
• Lever Handle Not Engaging:
  • Confirm that the spindle is correctly aligned and fully inserted through both keypads and the latch.
  • Check if the mounting screws are too tight or too loose, which can cause misalignment.
  • Ensure the latch bolt is not obstructed in the door frame.
• Difficulty Turning Lever:
  • Apply graphite lubricant as described in the Maintenance section.
  • Праверце на наяўнасць фізічных перашкод або смецця.

For further assistance, please contact JOUNJIP customer support.

Тэхнічныя характарыстыкі

Гарантыя і падтрымка

This JOUNJIP product comes with a 1-гадовая гарантыя ад вытворцы, ensuring quality and reliability. If you have any questions, require technical assistance, or need support with installation or operation, please do not hesitate to contact JOUNJIP customer support.

JOUNJIP is a family-run, US-based business committed to providing excellent customer service. They are available to help with quick explanations over the phone or even video calls to resolve any issues.

Figure 7: JOUNJIP Customer Support Information
