FORGING MOUNT Rotating TV Wall Mount HY9107-B Instruction Manual

1. Уводзіны

This manual provides detailed instructions for the safe and proper installation, operation, and maintenance of your FORGING MOUNT Rotating TV Wall Mount HY9107-B. Please read all instructions carefully before beginning installation to ensure correct setup and to prevent damage or injury.

2. Інфармацыя па бяспецы

УВАГА: Невыкананне гэтых інструкцый можа прывесці да сур'ёзных траўмаў, пашкоджання маёмасці або анулявання гарантыі.

• Ensure the mounting surface can safely support the combined weight of the mount and your TV.
• Не перавышайце максімальную грузападымальнасць 55 кг (25 фунтаў).
• This mount is designed for installation on wood studs, solid concrete walls, or brick walls. Не ўстанаўлівайце толькі ў гіпсакардон.
• Заўсёды выкарыстоўвайце прыбор для пошуку драўляных стойкаў, каб дакладна знайсці іх.
• If you are unsure about the installation process, consult a qualified professional installer.
• Не дапускайце дзяцей і хатніх жывёл падчас ўстаноўкі.

3. Змесціва ўпакоўкі

Verify that all components are present and undamaged before installation. If any parts are missing or defective, contact FORGING MOUNT customer service.

Выява: Зверхуview of all included components for the TV wall mount.

Кампаненты мацавання:

• Зборка насценнай пласціны
• Кранштэйны для тэлевізара (4 штукі)

Абсталяванне:

Image: Various screws, washers, and spacers provided for different TV models and wall types.

• Розныя шрубы для тэлевізара (M4, M6, M8)
• Шайбы і пракладкі
• Lag Bolts (for wall mounting)
• Concrete Anchors (for concrete/brick walls)

4. Неабходныя інструменты (не ўваходзяць у камплект)

• Адвёртка Phillips
• Электрычная дрыль
• Пузырьковый ўзровень
• Аловак
• Stud Finder (essential for wood stud installation)

5. Тэхнічныя характарыстыкі

Image: Common VESA patterns supported by the mount, showing horizontal and vertical measurements.

6. Настройка і ўстаноўка

Follow these steps for a secure installation. It is recommended to have two people for TV mounting.

Крок 1: Падрыхтуйце сцяну

1. Вызначыць месца мантажу: Determine the desired height and center of your TV. Use a stud finder to locate the center of a wood stud for wood stud installation. For concrete or brick walls, ensure the chosen location is solid.
2. Адзначыць кропкі свідравання: Hold the wall plate assembly against the wall at the desired height and use a pencil to mark the drilling points. Use a bubble level to ensure the marks are perfectly horizontal.
3. Прасвідраваць пілотныя адтуліны:
   • For Wood Studs: Drill pilot holes using a 3/16" (4.5mm) drill bit to a depth of 2.2" (55mm).
   • For Concrete/Brick Walls: Drill pilot holes using a 3/8" (10mm) drill bit to a depth of 2.4" (60mm). Insert concrete anchors into the drilled holes.

Image: Illustration of compatible wall types for installation: solid concrete, single wood stud, and brick wall. Note: Do not install in drywall alone.

Step 2: Install the Wall Plate Assembly

4. Align the wall plate assembly with the drilled holes. Attach it to the wall using the appropriate lag bolts and washers for your wall type. Tighten securely with a wrench.

Крок 3: Прымацуеце да тэлевізара кранштэйны

5. Пакладзеце тэлевізар экранам уніз на мяккую, чыстую паверхню, каб пазбегнуць драпін.
6. Attach the TV bracket arms to the back of your TV using the appropriate screws, washers, and spacers from the hardware kit. Ensure they are securely fastened.

Step 4: Hang TV on Mount

7. Carefully lift the TV and hook the attached TV brackets onto the wall plate assembly. Ensure the TV is securely seated on the mount.
8. Tighten any safety screws or locking mechanisms on the TV brackets to prevent accidental dislodgement.

Image: The FORGING MOUNT TV Wall Mount with a television securely attached, demonstrating its full motion capabilities.

7. Інструкцыя па эксплуатацыі

Rotation (Landscape to Portrait)

This mount allows for easy 90-degree rotation to switch your TV between landscape and portrait orientations. Gently rotate the TV to your desired orientation.

Image: A user demonstrating the 90-degree rotation feature of the TV mount, switching the display from horizontal to vertical.

Extension and Retraction

The mount can extend up to 5.3 inches from the wall and retract to a minimum of 2.36 inches. Gently pull or push the TV to adjust the distance from the wall.

Image: An illustration detailing the mount's ability to retract to 2.36 inches and extend up to 5.3 inches from the wall, optimizing space and viewныя вуглы.

Swivel and Tilt

The mount offers swivel and tilt capabilities for optimal viewing angles. Adjust the TV horizontally (swivel) or vertically (tilt) as needed. The mount allows for easy cable access even when retracted.

Image: A visual comparison highlighting the FORGING MOUNT's design for easy cable access behind the TV, contrasting with other mounts that make cable management difficult.

8. Тэхнічнае абслугоўванне

• Перыядычна правярайце ўсе шрубы і балты, каб пераканацца, што яны зацягнуты. Пры неабходнасці падцягвайце.
• Чысціце мацаванне мяккай сухой тканінай. Пазбягайце абразіўных ачышчальнікаў або растваральнікаў.
• Ensure smooth movement of the articulating arms. If movement becomes stiff, apply a small amount of silicone-based lubricant to the joints.

9. Выпраўленне непаладак

Issue: TV does not stop at desired position during rotation.

рашэнне: Adjust the two side screws on the rotation mechanism alternately using the provided tools until the desired tension is achieved. Refer to the detailed graphical installation guide for visual assistance.

10. Гарантыя і падтрымка

For warranty information or technical support, please refer to the product packaging or contact FORGING MOUNT customer service directly. Keep your purchase receipt for warranty claims.
