1. Уводзіны
This manual provides comprehensive instructions for the Inateck Wearable 1MP 2D QR Barcode Scanner, Nano 370 (Model N6022-BK). It covers product features, setup, operation, maintenance, and troubleshooting to ensure optimal performance and user experience.
Figure 1: Inateck Nano 370 Wearable Barcode Scanner overview.
2. Асаблівасці прадукту
- Ergonomic 60g Design: Features a 10° scanning angle designed to reduce wrist fatigue. Weighing only 60g with a breathable strap, it offers comfort for extended use.
- Voice Control & Hands-Free Operation: Activate scanning by saying "Scan." Supports automatic detection and a manual trigger for various workflows.
- 1MP High-Resolution Sensor: Equipped with a CMOS 1280*800 sensor, capable of instantly reading 1D/2D codes from smartphones and damaged labels.
- Bluetooth 5.3 & Triple Connection Modes: Provides stable transmission up to 40m with quick reconnection. Compatible with iOS, Android, and Windows via Bluetooth, 2.4G Dongle, or USB cable.
- 10 Hours Battery Life & Plug-and-Play: No drivers required for operation. The 800mAh battery supports a full day of continuous use. Features vibration and LED feedback for scan confirmation in noisy environments.
Figure 2: Ergonomic design highlights, including 60g weight, high-quality silicone, and 10° tilted lens for comfortable scanning.
Figure 3: Demonstrates the scanner's powerful megapixel resolution and ability to read various 1D, 2D, and QR codes, including those on screens or damaged labels.
3. Настройка
3.1 Зарадка прылады
Before first use, fully charge the scanner using the provided USB-C cable. The LED indicator will show charging status. A full charge provides up to 10 hours of continuous operation.
Figure 4: The scanner features an 800mAh battery, providing up to one day of continuous use.
3.2 Рэжымы падключэння
The Nano 370 scanner supports three connection methods:
- Bluetooth: For wireless connection to Windows, Mac OS, Linux, Android, and iOS devices.
- Правадны USB: Direct connection via USB-C cable to a computer.
- 2.4G Adapter: For wireless connection using the included 2.4G dongle.
Figure 5: Illustration of the three connection modes: Bluetooth for various operating systems, USB wired, and 2.4G adapter.
3.3 Inateck Scanner APP
For advanced configuration and efficient management, download the Inateck Scanner APP, available for both Android and iOS devices. This app allows for easy customization of scanner settings.
Figure 6: The Inateck Scanner APP supports simple and efficient configuration on Android and iOS devices.
4. Інструкцыя па эксплуатацыі
4.1 Нашэнне сканера
Attach the scanner to your wrist using the adjustable, breathable strap. Ensure it is snug but comfortable, allowing for free movement of your hand and wrist. The 10° tilted lens is designed for optimal scanning posture.
Figure 7: Proper hand and wrist positioning for effective scanning with the wearable device.
4.2 Рэжымы сканавання
The Nano 370 offers three scanning modes to suit different operational needs:
- Рэжым галасавога кіравання: Simply say "Scan" to activate the laser and read a barcode. This is ideal for hands-free operation, especially when handling heavy items.
- Automatic Sensor Mode: The scanner automatically detects and reads barcodes when they enter its field of view.
- Ручны рэжым запуску: Press the physical button on the scanner to activate the laser and scan a barcode.
Малюнак 8: Закончанаview of the three operational modes: voice command, automatic sensor, and manual button press.
4.3 Scan Confirmation
Upon successful scan, the device provides both vibration feedback and an LED indicator to confirm the reading, which is particularly useful in noisy environments.
5. Тэхнічнае абслугоўванне
- Уборка: Use a soft, dry cloth to clean the scanner's body and lens. Avoid abrasive materials or harsh chemicals.
- захоўванне: Захоўвайце сканер у прахалодным, сухім месцы, удалечыні ад прамых сонечных прамянёў і экстрэмальных тэмператур.
- Сыход за батарэяй: Каб падоўжыць тэрмін службы батарэі, пазбягайце частай поўнай разрадкі батарэі. Рэгулярна зараджайце прыладу.
- Замена раменьчыка: The breathable silicone strap is designed for durability. If replacement is needed, contact Inateck support.
6. Выпраўленне непаладак
| праблема | Магчымая прычына | Рашэнне |
|---|---|---|
| Сканер не ўключаецца | Нізкі зарад батарэі; няспраўнасць прылады | Charge the scanner; Contact support if issue persists. |
| Немагчыма падключыцца праз Bluetooth | Bluetooth not enabled on host device; Out of range; Pairing issue | Ensure Bluetooth is on; Move closer to host device; Re-pair the scanner. |
| Unable to read barcodes | Barcode damaged/unreadable; Incorrect scanning mode; Lens dirty | Try a different barcode; Switch scanning modes; Clean the lens. |
| Галасавое кіраванне не рэагуе | Voice control disabled; Noisy environment | Check settings in Inateck Scanner APP; Use manual trigger in noisy areas. |
7. Тэхнічныя характарыстыкі
- Нумар мадэлі: N6022-BK
- Марка: Інатэк
- Датчык: 1MP CMOS (1280*800)
- Кут сканавання: 10 Degrees (Ergonomic Tilt)
- Вага: 60 г
- Падключэнне: Bluetooth 5.3, USB-C, 2.4G Wireless (with adapter)
- Сумяшчальныя прылады: Desktop, Laptop, Tablet, Smartphone
- Сумяшчальная АС: Windows, Mac OS, Linux, Android, iOS
- акумулятар: 800mAh Lithium-Ion (included)
- Тэрмін службы батарэі: Да 10 гадзін бесперапыннага выкарыстання
- Хуткасць сканавання: 0.5 seconds per scan
- Зваротная сувязь: Vibration, LED Indicator
8. Гарантыя і падтрымка
Inateck products come with a standard manufacturer's warranty. For detailed warranty information, technical support, or service inquiries, please visit the official Inateck webсайт або звярніцеся ў службу падтрымкі кліентаў.
Official Inateck Webсайт: www.inateck.com
9. Відэа пра прадукт
Відэа 1: Оверview of the Inateck Nano 370 Wearable Barcode Scanner, showcasing its design, features, and various operational aspects.
