ABBIDOT AB-625 Long Range Dog Training Collar User Manual

Уводзіны

This manual provides detailed instructions for the safe and effective use of your ABBIDOT AB-625 Long Range Dog Training Collar. Please read all instructions carefully before using the product to ensure proper operation and the safety of your pet.

Змест пакета

Пераканайцеся, што ўсе пералічаныя ніжэй прадметы прысутнічаюць у вашай упакоўцы:

• Пульт дыстанцыйнага кіравання
• Прыёмнік-каўнер з раменьчыкам
• Кіраўніцтва карыстальніка
• Інструмент выпрабавання святла
• Кантактны вясновы ліст
• Зарадны кабель (USB-C)
• Silicone Caps (4x)
• Contact Points (4x)
• Папружка
• Заціск для рамяня

Малюнак 1: Усе кампаненты ў камплекце.

Настройка

1. Зарадка прылад

Before first use, fully charge both the remote control and the collar receiver. The devices feature USB-C charging for convenience.

• Connect the charging cable to the charging port on both the remote and the receiver.
• Поўная зарадка звычайна займае каля 2 гадзін.
• After charging, ensure the rubber cover on the receiver's charging port is securely sealed to maintain its IPX7 waterproof rating.

Figure 2: Charging the remote and collar receiver.

For a visual guide on charging, refer to the product video from 1:13 to 1:21.

2. Installing Contact Points and Silicone Caps

For dogs with long hair, install the longer metal contact points and corresponding silicone caps to ensure proper contact with the dog's skin. For short-haired dogs, the shorter contact points are usually sufficient.

• Screw the appropriate contact points into the receiver.
• Place the silicone caps over the contact points.

For a visual guide on installing contact points and silicone caps, refer to the product video from 1:22 to 1:29.

3. Attaching the Belt Clip (Optional)

The remote control comes with a detachable belt clip for convenient carrying.

• Align the belt clip with the groove on the back of the remote.
• Pinch the latch on the clip and press it down firmly until it clicks into place.

Figure 3: Attaching the belt clip to the remote.

For a visual guide on attaching the belt clip, refer to the product video from 1:30 to 1:36.

4. Adjusting the Collar Strap

The collar strap is adjustable to fit dogs with a neck circumference of 7.8 to 24.4 inches and weighing 10 to 120 pounds.

• Thread the strap through the buckle and adjust it to the appropriate size.
• Ensure the collar fits snugly but not too tightly. You should be able to fit two fingers comfortably between the collar and your dog's neck.
• Trim any excess strap if necessary.

Figure 4: Adjusting the collar strap for a proper fit.

For a visual guide on adjusting the collar, refer to the product video from 1:37 to 1:47.

Рэжымы працы

The ABBIDOT AB-625 offers four training modes: Tone, Vibration, Momentary Stimulation, and Continuous Stimulation, along with a multi-mode night light.

Малюнак 5: Закончанаview of the four training modes.

1. Tone Mode

Націсніце ТОН button on the remote to emit an audible sound from the receiver. This mode is ideal for attracting your dog's attention or as a warning signal.

2. Рэжым вібрацыі

Націсніце ВІБРА button on the remote to activate continuous vibration on the receiver for up to 10 seconds. The intensity of the vibration can be adjusted from 1 to 99 levels using the multi-control knob.

3. Stimulation Modes (Momentary & Continuous)

The collar offers two types of stimulation, with intensity levels adjustable from 1 to 99 using the multi-control knob.

• Momentary Stimulation: Delivers a single, brief pulse of stimulation.
• Continuous Stimulation: Delivers stimulation for as long as the button is pressed, up to a maximum of 10 seconds.

For a visual demonstration of Tone, Vibration, and Stimulation modes, refer to the product video from 0:12 to 0:24.

4. Adjusting Stimulation/Vibration Levels

• Павярнуць Multi-Control Knob on the remote to adjust the intensity level (1-99).
• Push the knob for 3 seconds to toggle between adjusting and saving the selected level.

For a visual guide on adjusting levels, refer to the product video from 0:38 to 0:45.

5. Night Light Modes

The collar receiver features a built-in light with three modes for visibility in low-light conditions.

• Націсніце СВЯТЛО button on the remote:
• First press: Constant On mode.
• Second press: Flashing mode.
• Трэцяе націсканне: Выкл.
• Націсніце і ўтрымлівайце СВЯТЛО button for 3 seconds to activate SOS signal mode.

Figure 6: Night light modes for enhanced visibility.

For a visual demonstration of the light modes, refer to the product video from 0:25 to 0:37.

Інструкцыі па спалучэнні

The collar and remote are pre-paired from the factory. If re-pairing is necessary, follow these steps:

• Ensure the collar receiver is turned off.
• На пульце дыстанцыйнага кіравання націсніце і ўтрымлівайце dog1/2 button for 3 seconds to unlock the remote and select the desired dog channel (e.g., Dog 1 or Dog 2).
• With the collar receiver off, press and hold the power button on the receiver for 5 seconds until the red and green lights flash alternately.
• While the lights are flashing, press the ТОН і ВІБРА buttons simultaneously on the remote to complete the pairing process.
• A successful pairing will be indicated by the collar receiver's light turning solid green.

For a visual guide on pairing, refer to the product video from 0:46 to 1:09.

Інструкцыі па бяспецы

Your dog's safety and comfort are paramount. Please adhere to these guidelines:

• Not for Puppies: This training collar is suitable for dogs above 6 months of age.
• Правільная пасадка: Ensure the collar fits snugly but not too tightly. It should allow two fingers to fit between the strap and your dog's neck. A loose fit can reduce effectiveness and cause skin irritation.
• Limited Wear Time: Do not leave the collar on your dog for more than 12 hours per day. Prolonged wear can lead to pressure necrosis (collar sores).
• Рэгулярны агляд: Check your dog's neck daily for any signs of skin irritation, redness, or sores. If irritation occurs, discontinue use until the skin heals.
• Кантраляванае выкарыстанне: Always supervise your dog when the training collar is in use.
• Avoid Over-Correction: Use stimulation modes responsibly and only when necessary. Start with the lowest effective level and gradually increase if needed.
• Бяспека вады: While the collar is IPX7 waterproof, ensure the charging port cover is sealed before exposing it to water.
• Not for Aggression: Do not use this collar to correct aggressive behavior. Consult a professional dog trainer for such issues.

Тэхнічнае абслугоўванне

• Уборка: Regularly clean the collar receiver and contact points with a damp cloth. Ensure the device is dry before charging.
• Сыход за раменьчыкам: Inspect the collar strap for wear and tear. Replace if damaged.
• захоўванне: Калі прылада не выкарыстоўваецца, захоўвайце яе ў прахалодным сухім месцы.
• Тэрмін службы батарэі: Charge the devices fully before long periods of inactivity to maintain battery health.

Ліквідацыю непаладак

Тэхнічныя характарыстыкі

• Нумар мадэлі: AB-625
• дыяпазон: Up to 1 Mile / 5280 Feet (open area)
• Рэжымы навучання: Tone, Continuous Vibration (1-99 levels), Momentary Stimulation (1-99 levels), Continuous Stimulation (1-99 levels)
• Начнік: 3 modes (Constant On, Flashing, SOS)
• Рэйтынг воданепранікальнасці: IPX7 for both Remote and Receiver
• Тэрмін службы батарэі: Up to 200 days standby for both Remote and Receiver
• Час зарадкі: Approximately 2 hours (USB-C)
• Памер каўняра: Neck circumference 7.8 - 24.4 inches
• Dog Weight Suitability: 10 - 120 фунта
• матэрыял: Штучная скура, пластык
• батарэі: Патрабуецца 2 батарэйка 9 В (у камплекце)
• Памеры ўпакоўкі: 6.02 х 4.06 х 2.09 цалі
• Вага прадмета: 12.8 унцыі

Figure 7: IPX7 Waterproof design for all weather conditions.

Figure 8: Extended range for absolute control.

Афіцыйнае відэа пра прадукт

Гарантыя і падтрымка

ABBIDOT products come with a Гарантыя 1 год. For any questions, concerns, or support needs, please contact our dedicated customer service team.

электронная пошта: Support@abbidot.com

Our team is here to help you with expertise and ensure your satisfaction.
