Sofirn SC33 Tactical Flashlight User Manual

1. Уводзіны

Дзякуй за пакупкуasing the Sofirn SC33 Tactical Flashlight. This compact and powerful EDC (Everyday Carry) light is designed for various applications, including outdoor adventures, emergencies, and daily use. It features a high-output LED, USB-C rechargeable battery, and multiple lighting modes, all housed in a durable, waterproof aluminum body.

2. Інфармацыя па бяспецы

• Do not shine the flashlight directly into eyes. The high lumen output can cause temporary vision impairment.
• Захоўваць у месцах, недаступных дзецям.
• Пераканайцеся, што батарэя ўстаўлена з правільнай палярнасцю.
• Do not disassemble the flashlight head or tail cap unless instructed for maintenance.
• Пазбягайце працяглага ўздзеяння экстрэмальных тэмператур або прамых сонечных прамянёў на ліхтарык.
• Use only recommended batteries and charging cables.

3. Змесціва ўпакоўкі

The Sofirn SC33 package includes the following items:

• Sofirn SC33 Flashlight x1
• Nylon Holster x1
• Rechargeable 21700 Battery (5000mAh) x1
• Зарадны кабель USB-C x1
• Кіраўніцтва карыстальніка x1
• Spare O-rings x2
• Браслет х1

Image: Sofirn SC33 Flashlight and included accessories.

4. Настройка

4.1 Устаноўка батарэі

Before first use, ensure the insulating paper disc is removed from the battery. Unscrew the tail cap, remove the orange insulating paper, and then reinsert the battery with the positive (+) end facing towards the flashlight head. Screw the tail cap back on securely.

Image: Removing the insulating paper from the battery.

4.2 Зарадка

The SC33 features a built-in USB-C charging port for convenient recharging. Simply connect the provided USB-C cable to the flashlight's port and a compatible USB power source. The indicator light on the flashlight will show charging status:

• Зялёны: 75% -100% акумулятар
• Міргае зялёным: 50% -75% акумулятар
• Чырвоны: 25% -50% акумулятар
• Мігае чырвоным: <25% battery

The flashlight can be charged using any standard USB-C phone cable, eliminating the need for special chargers.

Image: USB-C charging port and battery indicator.

4.3 Holster and Pocket Clip

The SC33 comes with a durable nylon holster and a two-way bolted pocket clip for versatile carrying options. The holster allows for secure attachment to belts or backpacks, while the pocket clip provides easy everyday carry.

Image: Flashlight in holster for hands-free carrying.

Image: Flashlight with durable metal pocket clip.

5. Інструкцыя па эксплуатацыі

The Sofirn SC33 features a tail e-switch for intuitive control of its various modes.

Image: Main Switch Operation Guide.

5.1 Асноўныя аперацыі

• 1 Націсніце: Turn the flashlight On or Off.
• Long Press (from On): Cycle through general lighting modes (Moonlight, Eco, Low, Medium, High).
• Long Press (from Off): Activate Moonlight Mode.
• Double Click (from On or Off): Activate Turbo Mode.

5.2 Спецыяльныя рэжымы

• Triple Click (from On or Off): Cycle through special modes: Strobe, SOS, and Beacon.

5.3 Stepless RampРэжым

• Quadruple Click (from On): Enter Stepless Dimming Mode. Hold the switch to smoothly adjust brightness up or down. Release and press again to change rampнага кірунку.

5.4 Рэжым блакіроўкі

The lock mode prevents accidental activation and extends the lifespan of your flashlight.

• Quadruple Click (from Off): Activate Lock Mode.
• Разблакіроўка: When the light is locked, double-click the switch.
• Disable Auto-Lockout: When the light is locked, quadruple-click the switch.

Image: Auto-Lockout Settings.

5.5 High-Performance Boost Driver

The SC33 incorporates a boost driver that regulates power from the battery and boosts voltage to the LED. This ensures the LED operates at its optimal current and brightness level, providing consistent illumination regardless of battery charge. Unlike many budget flashlights that dim as the battery drains, the SC33 maintains a steady brightness output.

Image: High-Performance Boost Driver ensures consistent brightness.

6. Тэхнічныя характарыстыкі

Image: ANSI/NEMA FL1 Chart for Sofirn SC33.

Image: Sofirn SC33 Flashlight.

Image: IPX8 Waterproof and Rugged Aluminum Body.

7. Тэхнічнае абслугоўванне

• Уборка: Працярыце ліхтарык мяккай, damp тканіна. Не выкарыстоўвайце агрэсіўныя хімікаты або абразіўныя матэрыялы.
• ўшчыльняльныя кольцы: Periodically inspect the O-rings for wear and tear. Replace them with the provided spare O-rings to maintain the IPX8 waterproof rating. Apply silicone grease to the O-rings to ensure a good seal.
• Тэмы: Keep the threads of the tail cap clean and lightly lubricated to ensure smooth operation and proper electrical contact.
• Сыход за батарэяй: Store the battery in a cool, dry place when not in use. If storing for extended periods, charge the battery to approximately 50% capacity.

8. Выпраўленне непаладак

• Ліхтарык не ўключаецца: Ensure the battery is fully charged and inserted correctly. Check for any insulating paper still present.
• Перарывістая праца: Clean the battery contacts and flashlight threads. Ensure the tail cap is screwed on tightly.
• Праблемы з зарадкай: Паспрабуйце іншы кабель USB-C або адаптар харчавання. Пераканайцеся, што порт зарадкі чысты і без смецця.
• Зніжэнне яркасці або часу працы: The battery may need to be recharged or replaced if it's old.

9. Гарантыя і падтрымка

The Sofirn SC33 Tactical Flashlight comes with a Гарантыя 1 год from the date of purchase. This warranty covers manufacturing defects and issues arising from normal use. For warranty claims or technical support, please contact Sofirn customer service through the retailer where the product was purchased or visit the official Sofirn webсайт.

10. Афіцыйнае відэа прадукту
