R.W.FLAME RFH-5001LCP-C4

R.W.FLAME 50-inch Smart Electric Fireplace User Manual

Model: RFH-5001LCP-C4

1. Важная інфармацыя па бяспецы

Калі ласка, прачытайце і ўсвядомце ўсю інструкцыю карыстальніка, уключаючы ўсю інфармацыю па тэхніцы бяспекі, перад падключэннем або выкарыстаннем гэтага прадукта. Невыкананне гэтага патрабавання можа прывесці да пажару, паражэння электрычным токам або сур'ёзных траўмаў.

  • Always disconnect the fireplace from the power supply before cleaning, performing maintenance, or relocating the unit.
  • Не выкарыстоўвайце гэты камін на вуліцы.
  • Гэты камін гарачы падчас выкарыстання. Каб пазбегнуць апёкаў, не дакранайцеся голай скуры да гарачых паверхняў.
  • Захоўвайце гаручыя матэрыялы, такія як мэбля, падушкі, пасцельная бялізна, паперы, адзенне і шторы, не менш за 3 футаў (0.9 м) ад пярэдняй часткі каміна.
  • Неабходная асаблівая асцярожнасць, калі любы камін выкарыстоўваецца дзецьмі або інвалідамі, а таксама кожны раз, калі камін застаецца ўключаным і без нагляду.
  • Не пракладвайце шнур пад дывановым пакрыццём. Не накрывайце шнур дыванкамі, дарожкамі або падобнымі пакрыццямі. Размясціце шнур далей ад зоны руху і так, каб аб яго не спатыкнуцца.
  • Убудаваная абарона ад перагрэву забяспечвае бяспечную працу.

2. Настройка і ўстаноўка

The R.W.FLAME 50-inch Smart Electric Fireplace can be installed as either a recessed unit or a wall-mounted unit. Ensure proper clearances as specified in the diagram below.

2.1 Locating Your Appliance

Refer to the diagram for recommended clearances from the ceiling and combustible materials.

Diagram showing fireplace dimensions and recommended clearances from ceiling and combustibles for wall-mounted installation.

Image: Fireplace dimensions and recommended clearances. Ceiling clearance: 8 inches (203mm). Clearance from combustibles: 36 inches (914mm).

2.2 Метады ўстаноўкі

This fireplace supports both wall-mounted and recessed installation. The following video provides detailed instructions for both methods.

Video: Detailed installation guide for the R.W.FLAME Smart Electric Fireplace, covering both embedded (recessed) and wall-mounted installation steps. This video demonstrates how to remove the mounting bracket, grip the glass frame with a suction cup, reserve a wall opening, pass the power cord, tuck the fireplace into the pit, drive screws, place decorative pieces (logs and crystals), and reinstall the glass panel for embedded installation. For wall-mounted installation, it shows fixing the bracket to the wall, using a level ruler, marking positions, drilling holes, inserting expansion screws (for concrete walls), installing the bracket, hanging the fireplace, tightening screws, and placing decorative pieces.

2.2.1 Убудаваная ўстаноўка

For recessed installation, it is necessary to reserve a wall opening and drill an inner hole for the power cable. Refer to the provided dimensions for your specific model.

Diagram illustrating wall-mounted versus recessed installation methods for the electric fireplace.

Image: Illustration of two installation methods: Wall-Mounted and Recessed.

2.2.2 Насценны мантаж

For wall-mounted installation, secure the provided bracket to the wall using appropriate hardware for your wall type. Ensure the bracket is level before hanging the fireplace.

Diagram showing air inlet and air outlet for the fireplace, indicating it can be fully or partially recessed in a wall.

Image: Heat vents with air inlet and air outlet, showing the fireplace can be fully or partially recessed in a wall.

2.3 Decorative Media Installation

The fireplace comes with both log and crystal options for the flame bed. Carefully place your chosen decorative media into the fireplace after installation and before reattaching the glass panel.

Product details showing various features including crystal and log options for the flame bed.

Image: Product details highlighting crystal and log options for the flame bed.

3. Інструкцыя па эксплуатацыі

Your R.W.FLAME electric fireplace offers multiple control options and customizable settings for a personalized experience.

3.1 Параметры кіравання

The fireplace can be controlled via touch-sensitive buttons on the unit, an LCD remote control, or a mobile application with Alexa/Google Assistant voice control integration.

Image showing the remote control, app control interface, Alexa connection, and control panel of the fireplace.

Image: Control options including App Control, Alexa Connecting, Control Panel, and Remote Control.

Diagram illustrating the functions of the control panel buttons: Sound, Flame Speed, Bed Color, Timer, Power ON/OFF, Heater, Dimmer, Flame Color.

Image: Control Panel Operation with a digital LED display, showing functions for Sound, Flame Speed, Bed Color, Timer, Heater, Dimmer, Flame Color, and Power ON/OFF.

3.2 Flame and Lighting Adjustment

Customize the visual ambiance with various flame patterns, colors, speeds, and brightness levels.

  • 12 Flame Patterns: Choose from a variety of flame styles.
  • 12 LED Flame Bed Color Modes: Select the perfect color for the ember bed.
  • 5 Flame Speed Settings: Адрэгулюйце хуткасць эфекту полымя.
  • 6 Lighting Brightness Levels: Control the overall brightness of the flame and flame bed.
  • Supports pure heating mode with lights off.
Image displaying 12 different flame colors and 12 flame bed colors, resulting in 144 color combinations.

Image: 12 Flame Colors and 12 Flame Bed Colors, offering 144 Color Combinations.

Image showing 12 adjustable flame colors and 5 flame speed settings, from slowest to fastest.

Image: 12 Flame Color Adjustable with 5 Flame Speed settings.

Image demonstrating 6 levels of flame brightness, from L0 (dimmer) to L5 (brighter).

Image: 6 Flame Brightness levels, from L0 (dimmer) to L5 (brighter).

3.3 рэжыму гуку

Enhance the fireplace experience with five simulated sound effects and adjustable volume.

  • Sound of burning wood
  • Sound of the waves
  • The chirping of birds
  • Sound of a stream flowing
  • Sound of Rain
Image showing the fireplace with sound waves emanating from it, and icons representing five different sound modes: burning wood, waves, birds, stream, and rain.

Image: 5 Sound Modes and 3 Volume Levels, with icons for Sound of burning wood, Sound of the waves, The chirping of birds, Sound of a stream flowing, and Sound of Rain.

3.4 Heating and Timer Functions

The fireplace provides efficient heating for up to 400 sq ft and includes a timer function for convenience.

  • Выдача цяпла: 1500 Вт.
  • Налады тэмпературы: Adjustable from 59-95°F.
  • Таймер: Set the operating duration from 1 to 8 hours.
Image showing the fireplace with text indicating Timer: 1-8 hours and Temperature: 59-95°F.

Image: Diversity Function showing Timer (1-8 hours) and Temperature (59-95°F).

3.5 Smart Integration

Connect your fireplace to your home Wi-Fi for advanced control and monitoring.

  • Падключэнне Wi-Fi: Enables whole-home smart interconnectivity.
  • Галасавое кіраванне: Compatible with Alexa and Google Assistant.
  • Кіраванне мабільнымі праграмамі: Operate and monitor your fireplace from anywhere using the Smart Life APP.
A woman on a couch with a cat, using voice commands to control the fireplace via Alexa, with logos for Alexa, Smart Life, and Google Home.

Image: Control from Anywhere via Smart Life APP and Voice Assistant Devices (Works with Amazon Alexa, Smart Life - Smart Living, Works with Google Home).

A man using a smartphone to monitor and control the electric fireplace via the Smart Life App.

Image: Energy Monitoring using the Smart Life APP to monitor and control the Electric Fireplace.

4. Тэхнічнае абслугоўванне

Рэгулярнае тэхнічнае абслугоўванне забяспечвае даўгавечнасць і аптымальную працу вашага электрычнага каміна. Заўсёды пераканайцеся, што прылада адключана ад сеткі і астыла, перш чым праводзіць любое тэхнічнае абслугоўванне.

  • Уборка: Выкарыстоўвайце мяккі, damp тканінай для чысткі вонкавых паверхняў. Не выкарыстоўвайце абразіўныя ачышчальнікі або спрэі.
  • Шкляная панэль: Clean the glass panel with a soft cloth and glass cleaner. Avoid scratching the surface.
  • Вентыляцыйныя адтуліны: Periodically check and clean the air inlet and outlet vents to ensure unobstructed airflow. Dust and debris can accumulate and affect heating efficiency.
  • захоўванне: Калі камін захоўваецца працяглы час, пераканайцеся, што ён чысты, сухі і захоўваецца ў бяспечным месцы.

5. Выпраўленне непаладак

If you encounter any issues with your R.W.FLAME electric fireplace, refer to the following common troubleshooting steps. If the problem persists, contact customer support.

  • Няма харчавання: Пераканайцеся, што шнур харчавання надзейна падключаны да спраўнай разеткі. Праверце аўтаматычны выключальнік у вашым доме.
  • Няма цяпла: Verify that the heater function is turned on and the temperature setting is above the ambient room temperature. Check for any obstructions in the air vents.
  • Эфект полымя не працуе: Ensure the flame effect is turned on. If using the remote, check battery levels.
  • Пульт дыстанцыйнага кіравання не адказвае: Replace the AAA batteries in the remote control. Ensure there are no obstructions between the remote and the fireplace sensor.
  • Праблемы з праграмай/галасавым кіраваннем: Verify your Wi-Fi connection and ensure the fireplace is properly paired with the Smart Life app and your Alexa/Google Assistant device.
  • Абарона ад перагрэву актывавана: If the unit shuts off unexpectedly, it may have overheated. Unplug the unit, wait 10-15 minutes for it to cool down, and check for any blocked air vents before plugging it back in.

6. Тэхнічныя характарыстыкі

АсаблівасцьДэталь
МаркаRWFLAME
Назва мадэлі850C4
Нумар мадэліRFH-5001LCP-C4
Крыніца харчаванняПравадная электрычная
Памеры прадукту (Д х Ш х У)5.39" Г x 50" Ш x 16.93" У
МатэрыялМетал
Тып аздабленняПафарбаваны
Тып ўстаноўкіWall Mount/Recessed
Цеплааддача1500 ват
АсаблівасціAdjustable Flame, LED Flame, Multicolor Flame, Overheat Protection, Timer
стыльСучасны
КолерЧорны
Тып нумараСпальня, хатні офіс, гасцёўня
Пакрыццё ацяплення400 кв
Канкрэтнае выкарыстанне прадуктуУ памяшканні
Number of Batteries (Remote)Патрабуецца 2 батарэйкі ААА
Вага прадмета50 фунта
Уключаныя кампанентыCrystal, Log, Remote Control, User Manual

7. Гарантыя і падтрымка

7.1 Інфармацыя аб гарантыі

This product comes with a limited warranty. For specific details regarding the warranty period and coverage, please refer to the warranty card included with your product or contact customer support.

7.2 Падтрымка кліентаў

For any questions, assistance, or to report issues, please contact R.W.FLAME customer support. You may also visit the official R.W.FLAME store for more information and resources.

Палітыка вяртання: 30-day easy returns for refund or replacement.

R.W.FLAME Store: Наведайце краму
