ZGOOD 18L Tabletop Class N High Pressure Steam Sterilizer User Manual

1. Прадукт скончыўсяview

The ZGOOD 18L Tabletop Class N High Pressure Steam Sterilizer is an automatic sterilizer designed for efficient and reliable sterilization of instruments and materials. It features a drying function and real-time monitoring of pressure and temperature, offering two preset programs and adjustable duration for specific sterilization requirements.

Асноўныя характарыстыкі:

• Efficient Automatic Sterilization: Operates at 1700W with easy operation, real-time pressure and temperature monitoring, and adjustable sterilization duration beyond preset programs (121°C/50 min, 134°C/40 min).
• Чысты святлодыёдны дысплей: Three LED displays for pressure, temperature, and dry status, providing clear process and time information.
• Automatic Pressure Release & Drying Function: Automatically releases internal pressure and discharges water/steam after completion. The drying function reduces the drying cycle and improves drying effectiveness for internal components and chambers.
• Durable Stainless Steel Chamber: Constructed from stainless steel with a double-layer stainless steel frame and an aluminum instrument tray for maximum capacity.
• Multiple Security Protections: Includes temperature and pressure overload protection, pressure safety lock (prevents door opening until pressure is zero), and safety door locks (ensures operation only when door is correctly locked).

2. Інструкцыі па тэхніцы бяспекі

Read all instructions carefully before operating the sterilizer. Failure to follow safety guidelines may result in injury or damage to the equipment.

• Электрабяспека: Ensure the electrical supply matches the unit's requirements (110 ~ 230 VAC). Do not operate with damaged cords or plugs.
• High Pressure and Temperature: The sterilizer operates under high pressure and temperature. Never attempt to open the door during operation or when the pressure gauge indicates internal pressure. The pressure safety lock prevents opening until pressure is zero.
• Небяспека апёку: Surfaces and internal components will be extremely hot after a cycle. Use appropriate protective gear (e.g., heat-resistant gloves) when handling sterilized items or performing maintenance.
• Якасць вады: Use only distilled water for operation to prevent mineral buildup and damage to the unit.
• Загрузка: Do not overload the chamber. Ensure items are arranged to allow proper steam circulation. Disinfection equipment should not be excessive and should not be stacked.
• Вентыляцыя: Забяспечце дастатковую вентыляцыю вакол прылады падчас працы.
• Аварыйнае адключэнне: In case of malfunction or emergency, immediately switch off the main power.

3. Змесціва ўпакоўкі

Пераканайцеся, што ўсе прадметы наяўныя пры распакаванні:

• Main Sterilizer Unit
• Instrument Racks
• Латок для інструментаў
• Шнур харчавання
• Кіраўніцтва карыстальніка
• Measuring Cup (for water)
• Tray Removal Tool

Image: The ZGOOD 18L Autoclave Sterilizer with its door open, revealing the stainless steel interior and instrument racks.

4. Кампаненты прадукту

Familiarize yourself with the main components of the sterilizer:

Image: Labeled diagram illustrating the key components of the ZGOOD 18L Autoclave Sterilizer.

5. Настройка

1. Распакаванне: Carefully remove the sterilizer and all accessories from the packaging. Retain packaging for future transport or storage.
2. Размяшчэнне: Place the unit on a stable, level, heat-resistant surface with adequate clearance for ventilation. Ensure it is away from heat sources and direct sunlight.
3. Падключэнне сілкавання: Connect the power cord to the sterilizer's power jack and then to a grounded electrical outlet that matches the specified voltage (110 ~ 230 VAC).
4. Add Distilled Water: Open the door by rotating the door handle counter-clockwise and pulling the door open. Using the provided measuring cup, add the appropriate amount of distilled water to the chamber. Important: Only use distilled water.

6. Інструкцыя па эксплуатацыі

1. Load Instruments: Place instruments and materials to be sterilized onto the instrument racks. Ensure items are not excessively stacked to allow proper steam penetration. Wrapped items can be placed in sterilized cloth.
2. Close and Secure Door: Close the sterilizer door and rotate the door handle clockwise to securely tighten it. Ensure the door is fully sealed.
3. Уключэнне: Flip the main switch to the "ON" position. The LED display will illuminate.
4. Select Sterilization Program: Use the control buttons on the LED display to select the desired temperature (121°C or 134°C) and sterilization time. The unit has preset programs (121°C/50 min; 134°C/40 min) but allows for adjustment.
5. Пачаць стэрылізацыю: Press the "Start" button to begin the sterilization cycle. The display will show the current temperature and pressure.
6. Сачыць за прагрэсам: The unit will automatically monitor temperature and pressure. The display will show "End" when the cycle is complete.
7. Функцыя сушкі: After sterilization, the unit will automatically release pressure and initiate the drying function to ensure items are dry.
8. Адчыненыя дзверы: Once the display shows "End" and the pressure gauge indicates zero pressure, carefully rotate the door handle counter-clockwise and open the door. Use the tray removal tool to prevent burns when retrieving hot items.

Малюнак: Examples of items suitable for sterilization in the autoclave, including exposed metal tools, wrapped items, and cotton fabrics.

7. Тэхнічнае абслугоўванне

Regular maintenance ensures optimal performance and longevity of your sterilizer.

• Штодзённая ўборка: After each use, wipe the interior of the chamber and the door gasket with a soft, damp cloth. Ensure no residue remains.
• Адвод вады: Regularly drain any remaining water from the reservoir. Refer to the specific drainage port location in the product diagram.
• Праверка пракладкі: Periodically inspect the door gasket for any signs of wear, cracks, or damage. A damaged gasket can lead to steam leaks and improper sterilization. Replace if necessary.
• Знешняя ачыстка: Keep the exterior of the unit clean and free of dust. Use a mild detergent if needed, but avoid abrasive cleaners.
• захоўванне: If storing the unit for an extended period, ensure it is clean, dry, and stored in a cool, dry place.

8. Выпраўленне непаладак

У гэтым раздзеле разглядаюцца распаўсюджаныя праблемы, з якімі вы можаце сутыкнуцца. Калі ў вас праблемы, якія тут не пералічаны, звярніцеся ў службу падтрымкі кліентаў.

9. Тэхнічныя характарыстыкі

10. Гарантыя і падтрымка

For warranty information, technical support, or service inquiries, please refer to the contact details provided with your purchase documentation or visit the official ZGOOD webсайт. Захоўвайце чэк аб куплі як пацвярджэнне пакупкі для гарантыйных прэтэнзій.
