1. Уводзіны
Thank you for choosing FREELICHT 4 Inch Retrofit LED Recessed Lighting. This product is designed to provide efficient, versatile, and high-quality illumination for various indoor spaces. This manual provides essential information for safe installation, operation, and maintenance of your new lighting fixtures. Please read it thoroughly before installation and retain it for future reference.
Выява 1.1: Канецview of the FREELICHT 4 Inch Retrofit LED Recessed Lighting fixture, showing the main light unit and the E26 adapter.
2. Інфармацыя па бяспецы
Каб знізіць рызыку пажару, паражэння электрычным токам або траўмаў людзей, калі ласка, выконвайце наступныя меры бяспекі:
- ПАПЯРЭДЖАННЕ: Рызыка паразы электрычным токам. Перад устаноўкай або абслугоўваннем адключыце сілкаванне ад засцерагальніка або аўтаматычнага выключальніка.
- ПАПЯРЭДЖАННЕ: Рызыка пажару. Тэмпература праваднікоў сілкавання павінна быць не менш за 90°C. Звярніцеся да кваліфікаванага электрыка, каб пераканацца ў правільнасці выбару праваднікоў адгалінавання.
- Do not install this fixture in a wet location. Suitable for damp толькі месцы.
- Пераканайцеся, што свяцільня правільна зазямлены.
- Do not attempt to alter or modify the fixture. Any alterations may void the warranty and create safety hazards.
- This product is IC Rated, meaning it is suitable for direct contact with insulation.
- This product is ETL and FCC certified, ensuring compliance with safety and performance standards.
3. Асаблівасці прадукту
- Selectable 5CCT: Choose from five color temperatures (2700K, 3000K, 4000K, 5000K, 6000K) to match any room ambiance.
- Smooth Dimmability: Compatible with most dimmers, allowing seamless brightness adjustment from 10% to 100%.
- Лёгкая ўстаноўка: Designed for 4-inch recessed housing cans with existing C-clips, utilizing a standard E26 base connection.
- Шырокае прымяненне: Suitable for various indoor spaces including living rooms, bedrooms, kitchens, hallways, basements, and offices. Damp-rated for use in bathrooms or covered outdoor areas.
- Надзейная бяспека: IC Rated and ETL-listed, ensuring safe operation when in contact with insulation and preventing overheating.
- Ультратонкі дызайн: Modern flat design provides a sleek, flush appearance against the ceiling.
Image 3.1: Visual representation of the five selectable color temperatures (2700K, 3000K, 4000K, 5000K, 6000K) and their suitability for different room styles like bedroom, kitchen, bathroom, living room, and hallway.
Image 3.2: Illustration demonstrating the smooth dimmability of the FREELICHT LED lights from 5% to 100% brightness, highlighting 700LM brightness and 7W wattage with no flicker or noise.
Image 3.3: Comparison image showing the difference between a traditional baffle trim recessed light and the modern flat design of the FREELICHT fixture, emphasizing a closer fit to the ceiling.
4. Што ў скрынцы
Кожная ўпакоўка змяшчае наступныя кампаненты:
- Святлодыёдны ўбудаваны свяцільня
- Springs (pre-attached or included for installation)
- E26 адаптар
- Раз'ём TP24
5. Настройка і ўстаноўка
Follow these steps for a simple and secure installation:
- Выключыць харчаванне: Before starting, ensure the power to the circuit is turned off at the circuit breaker or fuse box to prevent electric shock.
- Падрыхтуйце банку: Ensure your existing recessed housing can is 4 inches in diameter and has C-clips for installation.
- Screw E26 Base Adapter: Screw the provided E26 base adapter into the existing E26 socket within the recessed can.
- Connect TP24 Connector: Connect the TP24 connector from the LED light fixture to the TP24 connector on the E26 adapter. Ensure a secure connection.
- Adjust Color Temperature (Optional): Before pushing the light into the ceiling, locate the CCT switch on the back of the fixture and select your desired color temperature (2700K, 3000K, 4000K, 5000K, or 6000K).
- Push Light into Ceiling: Gently push the LED light fixture into the recessed can. The springs will secure the fixture in place.
- Аднавіць сілу: Once all fixtures are installed, restore power at the circuit breaker.
Image 5.1: Step-by-step visual guide for installing the FREELICHT recessed light. Steps include screwing in the E26 adapter, connecting the TP24 connector, and pushing the light into the ceiling.
Image 5.2: Diagram showing the dimensions of the FREELICHT 4 Inch recessed light, indicating it is suitable for 4-inch cans, with a diameter of 5.0 inches and a thickness of 1.02 inches.
6. Інструкцыя па эксплуатацыі
6.1. Рэгуляванне каляровай тэмпературы (CCT)
The FREELICHT recessed light features a 5CCT selectable switch, allowing you to choose from five distinct color temperatures. This switch is located on the back of the fixture. It is recommended to select your desired CCT before final installation into the ceiling. Once installed, you may need to carefully remove the fixture to access the switch if you wish to change the CCT.
Малюнак 6.1: Падрабязны view of the 5 CCT selectable switch on the back of the light fixture, showing options for Soft White (2700K), Warm White (3000K), Cool White (4000K), Daylight (5000K), and Cool Daylight (6000K).
6.2. Функцыянальнасць рэгулявання яркасці
This LED recessed light is designed for smooth dimming from 10% to 100% brightness. To utilize the dimming feature, you must connect the fixture to a compatible dimmer switch. Ensure your dimmer switch is suitable for LED lighting. The light is compatible with most non-smart dimmers on the market.
Image 6.2: Illustration of the light's dimming range, showing a smooth transition from 5% to 100% brightness in a living room setting.
6.3. Compatible Dimmers
For optimal dimming performance, use one of the following recommended dimmer models:
Image 6.3: A table listing various compatible dimmer models from brands like Lutron, Leviton, and Eaton, along with their star ratings for compatibility.
7. Тэхнічнае абслугоўванне
The FREELICHT LED Recessed Lighting requires minimal maintenance. Follow these guidelines to ensure longevity and optimal performance:
- Уборка: Перад чысткай пераканайцеся, што электрычнасць адключана. Працярыце прыбор мяккай, сухой або злёгку змочанай тканінай.amp cloth. Do not use harsh chemicals, abrasive cleaners, or solvents, as these can damage the finish or electrical components.
- агляд: Перыядычна правярайце наяўнасць няшчыльных злучэнняў або прыкмет пашкоджанняў. Калі выяўляюцца якія-небудзь праблемы, адключыце харчаванне і звярніцеся да кваліфікаванага электрыка.
- Няма частак, якія абслугоўваюцца карыстальнікам: Кампаненты святлодыёдаў інтэграваныя і не падлягаюць замене карыстальнікам. Не спрабуйце разбіраць свяцільнік.
8. Выпраўленне непаладак
If you encounter any issues with your FREELICHT LED Recessed Lighting, refer to the following common troubleshooting steps:
| праблема | Магчымая прычына | Рашэнне |
|---|---|---|
| Не гарыць святло | No power supply; Loose connection; Faulty fixture | Check circuit breaker/fuse; Ensure all connections (E26, TP24) are secure; Test with a known working fixture if possible. |
| Святло мігціць або гудзе | Несумяшчальны рэгулятар яркасці святла; няспраўная праводка | Replace with a compatible LED dimmer (refer to Section 6.3); Check wiring connections. |
| Няправільная каляровая тэмпература | CCT switch set incorrectly | Carefully remove fixture and adjust the CCT switch on the back to the desired setting. |
| Святло цьмянае або недастаткова яркае | Dimmer setting too low; Incorrect CCT setting for perceived brightness | Adjust dimmer to maximum brightness; Experiment with different CCT settings (higher K values often appear brighter). |
If the problem persists after trying these steps, please contact FREELICHT customer support for assistance.
9. Тэхнічныя характарыстыкі
| Марка | ФРЭЛІХТ |
| Назва мадэлі | Retrofit LED Recessed Lighting |
| Нумар мадэлі тавару | DLB01-D407T-700 120 |
| Памер | 4 цалі |
| Колер | Белы |
| Матэрыял | Polyamide fibre, Polycarbonate |
| Светлы колер | 5 CCT in One (2700K, 3000K, 4000K, 5000K, 6000K) |
| Яркасць | 700 люмен |
| Ватtage | 7 ват |
| тtage | 120 вольт |
| Памеры прадукту | 5.04 см Д х 5.04 см Ш х 1.02 см В |
| Вага прадмета | 7.15 фунтаў (для ўпакоўкі з 24 штук) |
| Выкарыстанне ў памяшканні/на вуліцы | У памяшканні (D)amp Ацэнка) |
| Асаблівасці | Adjustable Color Temperature, Dimmable, Energy Efficient |
| Спецыфікацыя Met | ETL, FCC |
| Тып мацавання | Потолочное мацаванне |
| Крыніца харчавання | Правадная электрычная |
| Патрабуюцца батарэі? | няма |
10. Гарантыя і падтрымка
FREELICHT provides a Гарантыя 2 год for this product, covering manufacturing defects and performance issues under normal use. We are committed to providing prompt and satisfactory after-sales service.
- Хуткі адказ: Чакайце адказу на вашы запыты на працягу 24 гадзін.
- New Replacements: If quality is a concern within the warranty period, we will provide new replacements free of charge.
For warranty claims, technical support, or any questions regarding your FREELICHT LED Recessed Lighting, please contact our customer service team through the retailer's platform or visit the official FREELICHT webсайт для кантактнай інфармацыі.
Image 10.1: Visual summary of FREELICHT's customer service commitment, including a 2-year warranty, 24-hour quick response, and free replacements for quality issues.
11. Відэарэсурсы
Currently, there are no official product videos from the seller available for embedding in this manual. Please check the product page on the retailer's website for any available video demonstrations or guides.
