eeTao UL Listed 3-Pin 36V AC/DC Adapter User Manual

1. Уводзіны

This manual provides essential information for the safe and efficient use of your eeTao UL Listed 3-Pin 36V AC/DC Adapter. This adapter is specifically designed for compatibility with Macwheel LNE-26 and LNE16 36V 7.5Ah Lithium-ion batteries used in electric folding bikes. Please read this manual thoroughly before use and retain it for future reference.

2. Інфармацыя па бяспецы

Каб забяспечыць бяспечную працу і прадухіліць пашкоджанні, выконвайце наступныя меры бяспекі:

• Уваходны кнtage: Адаптар падтрымлівае сусветны ўваходны аб'ёмtage range of 100-240VAC, 50/60Hz. Ensure your power outlet matches these specifications.
• Сумяшчальнасць: Use this adapter only with compatible devices, specifically Macwheel LNE-26 and LNE16 36V 7.5Ah Lithium-ion batteries. Using it with incompatible devices may cause damage or safety hazards.
• Асаблівасці абароны: This adapter includes Over VoltagАбарона ад электроннай напругі (OVP), абарона ад перагрузкі па току (OCP) і абарона ад кароткага замыкання (SCP) для абароны вашых прылад.
• Умовы навакольнага асяроддзя: Do not expose the adapter to water, moisture, or extreme temperatures. Use in a well-ventilated area.
• Фізічны ўрон: Do not use the adapter if the cord or connector is damaged. Do not attempt to open or repair the adapter yourself.
• Дзеці і хатнія жывёлы: Keep the adapter out of reach of children and pets.

3. Змесціва ўпакоўкі

Праверце, ці ёсць усе прадметы ў вашай упакоўцы:

• 1 x eeTao UL Listed 3-Pin 36V AC/DC Adapter
• 1 х шнур харчавання

Image 1: The eeTao 3-Pin 36V AC/DC Adapter shown with its detachable AC power cord.

4. Настройка

Follow these steps to set up your adapter for charging:

1. Connect the AC power cord to the adapter's input port.
2. Plug the AC power cord into a standard wall outlet (100-240VAC, 50/60Hz).
3. Connect the 3-pin output connector of the adapter to the charging port of your Macwheel LNE-26 or LNE16 electric folding bike battery. Ensure the connection is firm and secure.

Image 2: The eeTao adapter shown in use, connected to a Macwheel electric folding bike for charging.

5. Інструкцыя па эксплуатацыі

Once connected, the adapter will begin charging your battery. Observe the indicator light on the adapter for charging status:

• Чырвонае святло: Паказвае, што акумулятар зараз зараджаецца.
• Зялёнае святло: Indicates that charging is complete, and the battery is fully charged.

Image 3: Close-up of the adapter's indicator light, displaying red for active charging and green for a completed charge.

Always disconnect the adapter from the battery and the wall outlet once charging is complete to conserve energy and prolong the life of the adapter.

6. Тэхнічнае абслугоўванне

• Keep the adapter clean and free from dust. Use a dry, soft cloth for cleaning.
• Захоўвайце адаптар у прахалодным, сухім месцы, калі ён не выкарыстоўваецца.
• Avoid bending or crimping the power cords excessively.

7. Выпраўленне непаладак

If you encounter issues with charging, consider the following:

• No Charging Indicator Light:
  • Ensure the AC power cord is securely plugged into both the adapter and the wall outlet.
  • Verify the 3-pin connector is firmly seated in the battery's charging port.
  • Праверце разетку з дапамогай іншай прылады, каб пераканацца, што яна падае электрычнасць.
• Battery Not Charging (Red Light On, but no charge):
  • Rechargeable batteries have a limited lifespan, typically 1 to 3 years. An old or dead battery may not accept a charge, even if the charger is functioning correctly.
  • To determine if the charger is working, a voltmeter can be used to check the output voltage of the adapter. The output voltage should be approximately 36V DC.
  • Ensure the battery's voltage is 36V. The charger's output voltage is designed for 36V batteries.
• Перагрэў адаптара: Disconnect the adapter immediately and allow it to cool down. Ensure it is used in a well-ventilated area, away from direct sunlight or heat sources. If overheating persists, discontinue use and contact support.

8. Тэхнічныя характарыстыкі

9. Гарантыя і падтрымка

Your eeTao AC/DC Adapter is covered by the following warranty:

• Палітыка вяртання: Вяртанне за 30 дзён
• Палітыка абмену: 24 Months Exchange

For warranty claims or technical support, please contact your retailer or the manufacturer directly. Please have your product model number and purchase information ready.
